Products / Bows / Electrical USB2.0 3648-Pixel 16-bit CCD Line Camera with External Trigger

USB2.0 3648-Pixel 16-bit CCD Line Camera with External Trigger

$ 96.72

Description Mens Silver Figaro Chain 7mm This 7mm Italian Mens Silver Figaro Chain is great for large pendants, crosses and medallions. Made in the classic style, each chain is available in 55cm and 60cm lengths. Each chain is solid 925 sterling silver, secured by a lobster-claw style clasp and is imported from Italy Italian manufactured Sterling Silver Nickel free Tarnish resistant finish Lobster/Italian clasp Hallmarked The Mens 7mm Silver Figaro Chain is a timeless jewellery piece designed for men who want a bold and versatile everyday chain. Crafted in sterling silver, this mens silver chain combines durability with a clean polished finish that works effortlessly with both casual and formal outfits. The Figaro chain design remains one of the most searched and popular mens chain styles because of its distinctive alternating link pattern. The 7mm width gives this silver Figaro chain a strong masculine appearance while still remaining comfortable enough for daily wear. Whether worn on its own or layered with other chains, this sterling silver Figaro chain creates a confident and stylish look. Mens silver chains continue to grow in popularity across South Africa as more men invest in jewellery pieces that can be worn daily. A silver Figaro chain is one of the most versatile choices because it suits streetwear, luxury fashion, smart casual outfits, and everyday styling. The polished sterling silver finish gives the chain a premium appearance while maintaining durability for long-term use. This mens sterling silver chain is suitable for gifting, special occasions, birthdays, anniversaries, or upgrading your own jewellery collection. The Figaro chain style has remained popular for decades because of its balance between classic design and modern mens fashion trends. If you are searching for a mens silver Figaro chain in South Africa, this 7mm sterling silver chain offers the perfect balance between bold styling and everyday comfort. The chain features a secure clasp fastening designed to keep the necklace secure throughout the day while maintaining a comfortable fit around the neck. Sterling silver mens jewellery has become increasingly popular because it offers a luxury appearance at a more accessible price point compared to white gold or platinum jewellery. A mens sterling silver chain is easy to style and works well with rings, bracelets, watches, and pendants. The Figaro chain design also reflects light beautifully, helping the chain stand out without appearing overly flashy. This 7mm silver Figaro chain is designed for men who want a jewellery piece that feels substantial without becoming too heavy. The chain width makes it ideal for everyday wear while still giving the bold appearance many men look for when shopping for silver jewellery online. Shop mens silver chains online in South Africa with secure nationwide delivery from Arias Jewellery Palace. Mens Silver Chains South Africa FAQs What is a Figaro chain? A Figaro chain is a popular chain style made with a repeating pattern of shorter and longer links. It is widely used in mens jewellery because of its bold and timeless appearance. Is this mens Figaro chain made from sterling silver? Yes, this chain is crafted using sterling silver for durability, shine, and long-lasting wear. Can I wear this silver Figaro chain every day? Yes, this mens sterling silver chain is suitable for everyday wear and designed to remain comfortable throughout the day. What outfits does a silver Figaro chain work with? A silver Figaro chain works with casual outfits, smart casual looks, streetwear fashion, and formal menswear styling. Do you deliver mens silver chains across South Africa? Yes, secure nationwide delivery is available throughout South Africa. What payment options do you accept? You can pay for your order using any of the following payment options at checkout: Yoco® – For Credit Card payments PayFast – For Instant EFT or Credit Card payments PayJustNow – For payment over 3 equal interest-free instalments HappyPay Float Payflex Mobicred payment plan Direct Bank Transfer (EFT) Popular Gold Jewellery Categories: Gold Engagement Rings Gold Wedding Bands Gold Necklaces & Chains Gold Hoop & Stud Earrings Gold Bangles Gold Bracelets Gold Name Necklaces & Personalized Jewellery Gold Pendants

Customize your product

  • Product Details
  • Specifications
  • Downloads
  • Drawings
  • Packing List
  • Others
  • Software

Mightex’s TCN/TCE-1304-U line camera is a cost-effective high-performance B/W line camera, based on a single-line, 3648-pixel CCD chip with USB2.0 (480 Mb/s) interface. CCD line cameras have several advantages over their area-array counterparts, including high optical linear resolution that allows systems developers to use the cameras to capture two-dimensional (2-D) images by moving the object or the CCD perpendicularly to the scan line. TCE-1304-U is a compact line-scan camera ideal for a variety of OEM applications such as industry process control, optical spectroscopy and bio-medical imaging etc.. Setting up the TCE-1304-U line camera is very easy: one simply needs to install the camera’s application software into any PC, and then connect the line camera to the PC using a USB cable. There is no need to install a DAC card or to use an external power supply.

TCN/TCE-1304-UW camera is the window-less version of TCN/TCE-1304-U, with the glass window removed from the image sensor. Therefore, the former is more sensitive to UV and is more suitable for applications that involve coherent light sources.

Features

  • USB2.0 interface
  • No external power supply required
  • Optical integration time adjustable from 0.1ms to 6.5s
  • 3648 pixel silicon linear CCD array
  • 8μm x 200μm pixel size
  • 16-Bit A/D converter
  • Scan rate up to 138 scans/second
  • External trigger capability
  • 4 GPIO pins
  • SDK for user applications
  • Demo software with GUI
  • Compatible to Windows 2000, XP, Vista, 7/8/10

Applications

  • Industrial Process Control
  • Optical Spectroscopy

Performance Specifications

ParameterSpecification
CCDToshiba TCD1304DG
Number of Pixels3648
Pixel Size8μm x 200μm
Spectral Range300nm to 1050nm
200nm to 1050nm (Windowless version)
Pixel Output Clock0.5 MHz
Data Storage on Camera4 Frames
ADC Resolution16 bits
External TriggerYes
Trigger CableACC-CAM-DIN8
Exposure Time Range0.1ms – 6,500ms
GPIOYes (4 programmable I/O’s)
Frame Rate138 scans/second*
Host InterfaceUSB 2.0

* Frame Rate is dependent on exposure time. When exposure time is set to 0.1ms, the camera can achieve 138 scans/second.

SDK Features

Operation SystemsWindows 2000, XP, Vista, Windows 7, 8/8.1, and 10
Minimum RequirementRAM > 64M; Available Hard Disk Space > 10M
USB PortUSB2.0
Multiple CamerasSupported
Device DriverYes
Demo ApplicationYes
Library FilesYes (DLL files and Static Library file)
Example CodesYes (VC++ and Delphi)
Frame Attributes*Exposure Time, Time Stamp, Trigger Event Count, Over Exposure Detection.

* SDK will provide call back, which will send user Frame data and the related attributes of this frame, the attributes include: Exposure time, Time Stamp, Trigger Event Count and Over Exposure Flag.



Document Downloads:

Mechanical Drawing Downloads:

Software Download:

Mechanical Drawing Downloads:

Standard Packing List:

  1. 1x CCD Line Camera (w/o an imaging lens)
  2. 1x USB Cable (Note: Trigger cable ACC-CAM-DIN8 is NOT included and needs to be ordered separately)
  3. 1x CD (containing User’s Guide, SDK Manual, Windows-based application software with GUI, and example codes in VB, C++ and Delphi)

Software Download:

CCD Line Camera F-Mount Lens Adapter (P/N: ACC-LCM-F)

  1. Download ACC-LCM-F installation drawing (.pdf, 51.8kb);
  2. ACC-LCM-F lens adapter photograph

CCD Line Camera Spectral Response

Application Software GUI

Product specifications are subject to change without prior notice. All prices are FOB California, unless otherwise stated. Please call/email for volume pricing.
