USB2.0 3648-Pixel 16-bit CCD Line Camera with External Trigger

$ 99.88

Description Hollow Silver Double Round Curb Chain Italian manufactured Material: 925 Sterling Silver, Nickel Free Design: Hollow Double Round Curb Link Link Style: Interlocking tight curb links with a high-polish finish Lightweight Feel: Durable yet comfortable to wear, ideal for all-day wear without the added weight Clasp: Secure and easy-to-use signoretti clasp closure Length: 45cm Looking for a bold gold chain that doesn’t feel heavy around your neck? Our Hollow Silver Double Round Curb Chainis the perfect combo of luxury, comfort, and style. Explore our extensive collection of sterling silver bracelets, available in a wide variety of metals and gemstones to find the perfect gold studs for you. Introducing our collection of Sterling Silver Chains And Necklaces! Elevate your style with timeless elegance and exceptional craftsmanship. Discover Unmatched Brilliance Indulge in the allure of 925 sterling silver that’s durable and polished with unparalleled brilliance. Our handcrafted chains and necklaces are meticulously designed to captivate attention and become your signature accessory. Whether you’re dressing up for a special occasion or adding a touch of sophistication to your everyday look, our sterling silver pieces are the perfect choice. Unleash Your Inner Glow Enhance your natural beauty and radiate confidence with our 925 sterling silver chains and necklaces. Each piece is carefully crafted to accentuate your neckline and create a striking visual impact. From delicate chains that whisper elegance to statement necklaces that demand attention, our collection offers something for every style and personality. Exquisite Craftsmanship, Unmatched Quality We believe in delivering exceptional quality that lasts a lifetime. Our skilled artisans combine traditional techniques with contemporary designs, resulting in luxurious chains and necklaces that are truly exceptional. Every detail is meticulously refined, ensuring a seamless finish and comfortable fit, so you can wear our pieces with pride and joy. The Perfect Gift for Every Occasion Looking for the ideal gift that will be cherished forever? Look no further. Our sterling silver chains and necklaces make for unforgettable presents. Whether it’s a birthday, anniversary, or a token of appreciation, our collection offers a wide range of options to suit every taste and budget. Give the gift of elegance and watch their face light up with joy. Shop with Confidence What’s best with Aria Jewellery is that you can now come closer to buying this Hollow Silver Double Round Curb Chain you have always wanted. Thanks to our ������ ������ ������ ������ ���������� Mobicred �������������� �������� as a purchase option every time you shop for gold jewellery online. Which means now you don’t have to stop or limit yourself, go ahead and buy your Hollow Silver Double Round Curb Chain today. ���������������� is a simple and convenient revolving credit facility that allows you to safely shop online with more than 1,600 online stores in South Africa. Your Mobicred account allows you to make one single monthly payment for all of your online spend. If you have any questions about your order don’t hesitate to call or message our team.

Customize your product

  • Product Details
  • Specifications
  • Downloads
  • Drawings
  • Packing List
  • Others
  • Software

Mightex’s TCN/TCE-1304-U line camera is a cost-effective high-performance B/W line camera, based on a single-line, 3648-pixel CCD chip with USB2.0 (480 Mb/s) interface. CCD line cameras have several advantages over their area-array counterparts, including high optical linear resolution that allows systems developers to use the cameras to capture two-dimensional (2-D) images by moving the object or the CCD perpendicularly to the scan line. TCE-1304-U is a compact line-scan camera ideal for a variety of OEM applications such as industry process control, optical spectroscopy and bio-medical imaging etc.. Setting up the TCE-1304-U line camera is very easy: one simply needs to install the camera’s application software into any PC, and then connect the line camera to the PC using a USB cable. There is no need to install a DAC card or to use an external power supply.

TCN/TCE-1304-UW camera is the window-less version of TCN/TCE-1304-U, with the glass window removed from the image sensor. Therefore, the former is more sensitive to UV and is more suitable for applications that involve coherent light sources.

Features

  • USB2.0 interface
  • No external power supply required
  • Optical integration time adjustable from 0.1ms to 6.5s
  • 3648 pixel silicon linear CCD array
  • 8μm x 200μm pixel size
  • 16-Bit A/D converter
  • Scan rate up to 138 scans/second
  • External trigger capability
  • 4 GPIO pins
  • SDK for user applications
  • Demo software with GUI
  • Compatible to Windows 2000, XP, Vista, 7/8/10

Applications

  • Industrial Process Control
  • Optical Spectroscopy

Performance Specifications

ParameterSpecification
CCDToshiba TCD1304DG
Number of Pixels3648
Pixel Size8μm x 200μm
Spectral Range300nm to 1050nm
200nm to 1050nm (Windowless version)
Pixel Output Clock0.5 MHz
Data Storage on Camera4 Frames
ADC Resolution16 bits
External TriggerYes
Trigger CableACC-CAM-DIN8
Exposure Time Range0.1ms – 6,500ms
GPIOYes (4 programmable I/O’s)
Frame Rate138 scans/second*
Host InterfaceUSB 2.0

* Frame Rate is dependent on exposure time. When exposure time is set to 0.1ms, the camera can achieve 138 scans/second.

SDK Features

Operation SystemsWindows 2000, XP, Vista, Windows 7, 8/8.1, and 10
Minimum RequirementRAM > 64M; Available Hard Disk Space > 10M
USB PortUSB2.0
Multiple CamerasSupported
Device DriverYes
Demo ApplicationYes
Library FilesYes (DLL files and Static Library file)
Example CodesYes (VC++ and Delphi)
Frame Attributes*Exposure Time, Time Stamp, Trigger Event Count, Over Exposure Detection.

* SDK will provide call back, which will send user Frame data and the related attributes of this frame, the attributes include: Exposure time, Time Stamp, Trigger Event Count and Over Exposure Flag.



Document Downloads:

Mechanical Drawing Downloads:

Software Download:

Mechanical Drawing Downloads:

Standard Packing List:

  1. 1x CCD Line Camera (w/o an imaging lens)
  2. 1x USB Cable (Note: Trigger cable ACC-CAM-DIN8 is NOT included and needs to be ordered separately)
  3. 1x CD (containing User’s Guide, SDK Manual, Windows-based application software with GUI, and example codes in VB, C++ and Delphi)

Software Download:

CCD Line Camera F-Mount Lens Adapter (P/N: ACC-LCM-F)

  1. Download ACC-LCM-F installation drawing (.pdf, 51.8kb);
  2. ACC-LCM-F lens adapter photograph

CCD Line Camera Spectral Response

Application Software GUI
