USB2.0 3648-Pixel 16-bit CCD Line Camera with External Trigger

$ 98.17

Description Faith, Love And Hope Bracelet Our Faith, Love And Hope Bracelet is custom made per order, please allow 7-10 days production and delivery time for custom made orders Due to the individually handmade nature of our rings, some weights and measurements may vary slightly. What’s best with Aria Jewellery is that you can now come closer to buying this Personalised Faith, Love And Hope Bracelet thanks to our buy now and pay later Mobicred payment plan as a purchase option every time you shop for your favourite personalised bracelets Which means now you don’t have to stop or limit yourself, go ahead and buy your Faith, Love And Hope Bracelet today. Mobicred is a simple and convenient revolving credit facility that allows you to safely shop online with more than 1,600 online stores in South Africa. Your Mobicred account allows you to make one single monthly payment for all of your online spend. Personalised Bracelets – Engraved & Custom Designs Made Just for You A personalised bracelet is more than jewellery — it’s a piece of wearable art with a message that’s uniquely yours. Our collection includes engraved bangles, adjustable chain bracelets, and custom charm designs to suit every style and occasion. Choose your preferred finish — from sterling silver to gold-plated or rose gold — and add your own engraving, such as names, initials, special dates, or a short phrase. You can even select from a variety of fonts and symbols to create something truly unique. Personalised bracelets make perfect friendship gifts, anniversary keepsakes, or special occasion accessories. Our expert jewellers carefully craft each bracelet to your specifications, ensuring every detail is flawless. Whether you’re looking for a sleek minimalist bar bracelet, a boho-style charm bracelet, or a timeless bangle, our collection offers something for everyone. Many of our customers love pairing their bracelet with a Matching Personalised Necklace or Engraved Ring to create a complete jewellery set. Choose from our inspirational designs or create your own jewellery, celebrating your accomplishments, reminding you of your goals and values or simply treasuring what means most to you Keep your loved one’s close by adding custom engraving to our hand-made collection of Sterling Silver or solid Gold personalised bracelets, necklaces and rings FAQs – Personalised Bracelets Q1: Can I add more than one engraving on a bracelet?Yes, depending on the design, we can add multiple engravings or charms. Q2: Are personalised bracelets adjustable?We offer adjustable chain styles as well as fixed sizes. Sizing information is provided with each product. Q3: What’s the best occasion to gift a personalised bracelet?They’re ideal for birthdays, anniversaries, Valentine’s Day, graduations, and friendship gifts. Q4: Can I add symbols like hearts or infinity signs?Yes, many of our designs allow symbols, icons, or small motifs in addition to text. Q5: How should I care for my personalised bracelet?Avoid water, perfumes, and harsh chemicals to keep your bracelet looking new. Store it in a jewellery box when not in use. Q6: What payment options do you accept? You can pay for your order using any of the following payment options at checkout: Yoco® – For Credit Card payments PayFast – For Instant EFT or Credit Card payments PayJustNow – For payment over 3 equal interest-free instalments HappyPay Float Payflex Mobicred payment plan Direct Bank Transfer (EFT)

Customize your product

  • Product Details
  • Specifications
  • Downloads
  • Drawings
  • Packing List
  • Others
  • Software

Mightex’s TCN/TCE-1304-U line camera is a cost-effective high-performance B/W line camera, based on a single-line, 3648-pixel CCD chip with USB2.0 (480 Mb/s) interface. CCD line cameras have several advantages over their area-array counterparts, including high optical linear resolution that allows systems developers to use the cameras to capture two-dimensional (2-D) images by moving the object or the CCD perpendicularly to the scan line. TCE-1304-U is a compact line-scan camera ideal for a variety of OEM applications such as industry process control, optical spectroscopy and bio-medical imaging etc.. Setting up the TCE-1304-U line camera is very easy: one simply needs to install the camera’s application software into any PC, and then connect the line camera to the PC using a USB cable. There is no need to install a DAC card or to use an external power supply.

TCN/TCE-1304-UW camera is the window-less version of TCN/TCE-1304-U, with the glass window removed from the image sensor. Therefore, the former is more sensitive to UV and is more suitable for applications that involve coherent light sources.

Features

  • USB2.0 interface
  • No external power supply required
  • Optical integration time adjustable from 0.1ms to 6.5s
  • 3648 pixel silicon linear CCD array
  • 8μm x 200μm pixel size
  • 16-Bit A/D converter
  • Scan rate up to 138 scans/second
  • External trigger capability
  • 4 GPIO pins
  • SDK for user applications
  • Demo software with GUI
  • Compatible to Windows 2000, XP, Vista, 7/8/10

Applications

  • Industrial Process Control
  • Optical Spectroscopy

Performance Specifications

ParameterSpecification
CCDToshiba TCD1304DG
Number of Pixels3648
Pixel Size8μm x 200μm
Spectral Range300nm to 1050nm
200nm to 1050nm (Windowless version)
Pixel Output Clock0.5 MHz
Data Storage on Camera4 Frames
ADC Resolution16 bits
External TriggerYes
Trigger CableACC-CAM-DIN8
Exposure Time Range0.1ms – 6,500ms
GPIOYes (4 programmable I/O’s)
Frame Rate138 scans/second*
Host InterfaceUSB 2.0

* Frame Rate is dependent on exposure time. When exposure time is set to 0.1ms, the camera can achieve 138 scans/second.

SDK Features

Operation SystemsWindows 2000, XP, Vista, Windows 7, 8/8.1, and 10
Minimum RequirementRAM > 64M; Available Hard Disk Space > 10M
USB PortUSB2.0
Multiple CamerasSupported
Device DriverYes
Demo ApplicationYes
Library FilesYes (DLL files and Static Library file)
Example CodesYes (VC++ and Delphi)
Frame Attributes*Exposure Time, Time Stamp, Trigger Event Count, Over Exposure Detection.

* SDK will provide call back, which will send user Frame data and the related attributes of this frame, the attributes include: Exposure time, Time Stamp, Trigger Event Count and Over Exposure Flag.



Standard Packing List:

  1. 1x CCD Line Camera (w/o an imaging lens)
  2. 1x USB Cable (Note: Trigger cable ACC-CAM-DIN8 is NOT included and needs to be ordered separately)
  3. 1x CD (containing User’s Guide, SDK Manual, Windows-based application software with GUI, and example codes in VB, C++ and Delphi)

Software Download:

CCD Line Camera F-Mount Lens Adapter (P/N: ACC-LCM-F)

  1. Download ACC-LCM-F installation drawing (.pdf, 51.8kb);
  2. ACC-LCM-F lens adapter photograph

CCD Line Camera Spectral Response

Application Software GUI

Product specifications are subject to change without prior notice. All prices are FOB California, unless otherwise stated. Please call/email for volume pricing.
