USB2.0 3648-Pixel 16-bit CCD Line Camera with External Trigger

$ 48.95

The Lovu T-Shirt Dress is one of those easy wardrobe staples that you’ll find yourself wearing again and again. Designed for comfort and versatility, this relaxed-fitting dress offers an effortless look that works for a variety of occasions. Made from a soft, comfortable fabric, the T-Shirt Dress is perfect for everyday wear. Whether you’re heading out for coffee, running errands, enjoying a weekend away, travelling, or simply looking for a comfortable outfit for the day, this dress makes getting dressed simple. The relaxed silhouette offers comfortable movement while creating an easy, laid-back look that can be styled in countless ways. Wear it with sneakers for a casual daytime outfit, layer it with a denim jacket during cooler weather, or dress it up with accessories and boots for a more polished look. Why You’ll Love It Relaxed and comfortable fit Soft fabric designed for everyday wear Easy to dress up or down Suitable for every season Comfortable enough for all-day wear Perfect for travel, weekends, and everyday outings Timeless design you’ll wear year after year Fabric & Feel Made from a soft, comfortable fabric selected for everyday wear, the T-Shirt Dress offers ease of movement and all-day comfort while maintaining a neat appearance. Style It Your Way Pair your T-Shirt Dress with sneakers and a crossbody bag for a casual daytime look, or style it with ankle boots and a jacket when the temperature drops. Add your favourite accessories to create a look that suits your personal style. Inclusive Sizing At Lovu, we believe every woman deserves clothing that fits beautifully and feels comfortable. Our garments are available in a full range of sizes from XS to 5XL, with custom sizing options available. Whether you’re petite, tall, curvy, or somewhere in between, we’re committed to creating clothing that helps you feel confident and comfortable. Need Help Choosing a Fabric?Visit our fabric options page to learn more about our available fabrics, their feel, stretch, and suitability for different garment styles. Questions Before Ordering?We’re happy to help. Please visit our contact us page if you need assistance with sizing, fabric selection, customisations, or choosing the best option for your needs. Lead Time Please allow 1–10 working days for your garment to be made. During periods of load-shedding or high order volumes, lead times may increase by an additional 2–5 working days. If you require your order by a specific date, please contact us before placing your order. Please note that slight variations in color may occur due to differences in screen settings. Fabric availability may also change from time to time; all listed options are currently in stock. At  Lovu, we believe beautiful clothing should fit beautifully on every body. All of our garments can be customised for tall and plus size fits as part of our Tall & Plus Size Collection. From added length adjustments to more comfortable sizing and proportions, each piece is thoughtfully made to offer a flattering and comfortable fit while maintaining our signature timeless linen aesthetic. Proudly made in South Africa with a focus on comfort, individuality and effortless style. plan it plan it

Customize your product

  • Product Details
  • Specifications
  • Downloads
  • Drawings
  • Packing List
  • Others
  • Software

Mightex’s TCN/TCE-1304-U line camera is a cost-effective high-performance B/W line camera, based on a single-line, 3648-pixel CCD chip with USB2.0 (480 Mb/s) interface. CCD line cameras have several advantages over their area-array counterparts, including high optical linear resolution that allows systems developers to use the cameras to capture two-dimensional (2-D) images by moving the object or the CCD perpendicularly to the scan line. TCE-1304-U is a compact line-scan camera ideal for a variety of OEM applications such as industry process control, optical spectroscopy and bio-medical imaging etc.. Setting up the TCE-1304-U line camera is very easy: one simply needs to install the camera’s application software into any PC, and then connect the line camera to the PC using a USB cable. There is no need to install a DAC card or to use an external power supply.

TCN/TCE-1304-UW camera is the window-less version of TCN/TCE-1304-U, with the glass window removed from the image sensor. Therefore, the former is more sensitive to UV and is more suitable for applications that involve coherent light sources.

Features

  • USB2.0 interface
  • No external power supply required
  • Optical integration time adjustable from 0.1ms to 6.5s
  • 3648 pixel silicon linear CCD array
  • 8μm x 200μm pixel size
  • 16-Bit A/D converter
  • Scan rate up to 138 scans/second
  • External trigger capability
  • 4 GPIO pins
  • SDK for user applications
  • Demo software with GUI
  • Compatible to Windows 2000, XP, Vista, 7/8/10

Applications

  • Industrial Process Control
  • Optical Spectroscopy

Performance Specifications

ParameterSpecification
CCDToshiba TCD1304DG
Number of Pixels3648
Pixel Size8μm x 200μm
Spectral Range300nm to 1050nm
200nm to 1050nm (Windowless version)
Pixel Output Clock0.5 MHz
Data Storage on Camera4 Frames
ADC Resolution16 bits
External TriggerYes
Trigger CableACC-CAM-DIN8
Exposure Time Range0.1ms – 6,500ms
GPIOYes (4 programmable I/O’s)
Frame Rate138 scans/second*
Host InterfaceUSB 2.0

* Frame Rate is dependent on exposure time. When exposure time is set to 0.1ms, the camera can achieve 138 scans/second.

SDK Features

Operation SystemsWindows 2000, XP, Vista, Windows 7, 8/8.1, and 10
Minimum RequirementRAM > 64M; Available Hard Disk Space > 10M
USB PortUSB2.0
Multiple CamerasSupported
Device DriverYes
Demo ApplicationYes
Library FilesYes (DLL files and Static Library file)
Example CodesYes (VC++ and Delphi)
Frame Attributes*Exposure Time, Time Stamp, Trigger Event Count, Over Exposure Detection.

* SDK will provide call back, which will send user Frame data and the related attributes of this frame, the attributes include: Exposure time, Time Stamp, Trigger Event Count and Over Exposure Flag.



Document Downloads:

Mechanical Drawing Downloads:

Software Download:

Mechanical Drawing Downloads:

Standard Packing List:

  1. 1x CCD Line Camera (w/o an imaging lens)
  2. 1x USB Cable (Note: Trigger cable ACC-CAM-DIN8 is NOT included and needs to be ordered separately)
  3. 1x CD (containing User’s Guide, SDK Manual, Windows-based application software with GUI, and example codes in VB, C++ and Delphi)

Software Download:

CCD Line Camera F-Mount Lens Adapter (P/N: ACC-LCM-F)

  1. Download ACC-LCM-F installation drawing (.pdf, 51.8kb);
  2. ACC-LCM-F lens adapter photograph

CCD Line Camera Spectral Response

Application Software GUI

Product specifications are subject to change without prior notice. All prices are FOB California, unless otherwise stated. Please call/email for volume pricing.
