USB2.0 3648-Pixel 16-bit CCD Line Camera with External Trigger

$ 17.85

Itty Bitty Kids: Beige Diamanté Bow Clog Sandals Elevate your little one’s everyday look with a touch of sparkle. Our Itty Bitty Kids Beige Diamanté Bow Clog Sandalscombine the practical, easy-wear nature of a clog with the sophisticated charm of a dress shoe. In a versatile neutral beige, these are the perfect finishing touch for everything from party dresses to summer shorts. Shimmering Diamanté Details The star of the show is the oversized, structured bow across the vamp. Adorned with shimmering diamanté crystals, this detail catches the light with every step, adding a magical twinkle to your child’s stride. The crystals are securely set to ensure they stay dazzling through playdates and special events alike. Designed for Little Explorers Ultra-Lightweight Clog Style: Crafted from high-quality, lightweight materials that won’t weigh down small feet, making them perfect for all-day wear. Supportive Heel Strap: Features a pivotable heel strap that can be worn forward for an easy slip-on clog feel or behind the heel for a secure, stay-on fit. Ventilated Comfort: Side ports provide essential breathability, keeping feet cool and comfortable during warmer months. Easy Care: The smooth, beige finish is water-friendly and incredibly easy to clean—simply wipe away dirt with a damp cloth. Product Specifications FeatureDetailsColorClassic Neutral Beige / OatmealAccentOversized Bow with Diamanté CrystalsMaterialPremium EVA / SyntheticVersatility2-in-1 Design (Slide or Secured Sandal)FitRoomy & Breathable Itty Bitty Kids: Size Guide To ensure the perfect fit for your little one’s new sandals, please refer to the conversion chart below. We recommend measuring your child’s foot from heel to toe and adding approximately 0.5cm to 1cm for growth room. Size Conversion Table EUR SizeUK Kids SizeApprox. Foot Length (cm)Approx. Age Range19311.5 cm9 – 12 Months203.5 – 412.3 cm12 – 15 Months214.5 – 513.0 cm15 – 18 Months225.513.7 cm18 – 24 Months236 – 6.514.3 cm2 Years24715.0 cm2 – 2.5 Years257.5 – 815.7 cm2.5 – 3 Years268.5 – 916.3 cm3 Years279.517.0 cm3.5 – 4 Years281017.7 cm4 Years291118.3 cm5 Years3011.5 – 1219.0 cm5.5 – 6 Years3112.5 – 1319.7 cm6 – 7 Years32120.3 cm7 Years331.5 – 221.0 cm8 Years342.521.7 cm9 Years35322.3 cm10 Years363.5 – 423.0 cm11 Years

Customize your product

  • Product Details
  • Specifications
  • Downloads
  • Drawings
  • Packing List
  • Others
  • Software

Mightex’s TCN/TCE-1304-U line camera is a cost-effective high-performance B/W line camera, based on a single-line, 3648-pixel CCD chip with USB2.0 (480 Mb/s) interface. CCD line cameras have several advantages over their area-array counterparts, including high optical linear resolution that allows systems developers to use the cameras to capture two-dimensional (2-D) images by moving the object or the CCD perpendicularly to the scan line. TCE-1304-U is a compact line-scan camera ideal for a variety of OEM applications such as industry process control, optical spectroscopy and bio-medical imaging etc.. Setting up the TCE-1304-U line camera is very easy: one simply needs to install the camera’s application software into any PC, and then connect the line camera to the PC using a USB cable. There is no need to install a DAC card or to use an external power supply.

TCN/TCE-1304-UW camera is the window-less version of TCN/TCE-1304-U, with the glass window removed from the image sensor. Therefore, the former is more sensitive to UV and is more suitable for applications that involve coherent light sources.

Features

  • USB2.0 interface
  • No external power supply required
  • Optical integration time adjustable from 0.1ms to 6.5s
  • 3648 pixel silicon linear CCD array
  • 8μm x 200μm pixel size
  • 16-Bit A/D converter
  • Scan rate up to 138 scans/second
  • External trigger capability
  • 4 GPIO pins
  • SDK for user applications
  • Demo software with GUI
  • Compatible to Windows 2000, XP, Vista, 7/8/10

Applications

  • Industrial Process Control
  • Optical Spectroscopy

Performance Specifications

ParameterSpecification
CCDToshiba TCD1304DG
Number of Pixels3648
Pixel Size8μm x 200μm
Spectral Range300nm to 1050nm
200nm to 1050nm (Windowless version)
Pixel Output Clock0.5 MHz
Data Storage on Camera4 Frames
ADC Resolution16 bits
External TriggerYes
Trigger CableACC-CAM-DIN8
Exposure Time Range0.1ms – 6,500ms
GPIOYes (4 programmable I/O’s)
Frame Rate138 scans/second*
Host InterfaceUSB 2.0

* Frame Rate is dependent on exposure time. When exposure time is set to 0.1ms, the camera can achieve 138 scans/second.

SDK Features

Operation SystemsWindows 2000, XP, Vista, Windows 7, 8/8.1, and 10
Minimum RequirementRAM > 64M; Available Hard Disk Space > 10M
USB PortUSB2.0
Multiple CamerasSupported
Device DriverYes
Demo ApplicationYes
Library FilesYes (DLL files and Static Library file)
Example CodesYes (VC++ and Delphi)
Frame Attributes*Exposure Time, Time Stamp, Trigger Event Count, Over Exposure Detection.

* SDK will provide call back, which will send user Frame data and the related attributes of this frame, the attributes include: Exposure time, Time Stamp, Trigger Event Count and Over Exposure Flag.



Document Downloads:

Mechanical Drawing Downloads:

Software Download:

Mechanical Drawing Downloads:

Standard Packing List:

  1. 1x CCD Line Camera (w/o an imaging lens)
  2. 1x USB Cable (Note: Trigger cable ACC-CAM-DIN8 is NOT included and needs to be ordered separately)
  3. 1x CD (containing User’s Guide, SDK Manual, Windows-based application software with GUI, and example codes in VB, C++ and Delphi)

Software Download:

CCD Line Camera F-Mount Lens Adapter (P/N: ACC-LCM-F)

  1. Download ACC-LCM-F installation drawing (.pdf, 51.8kb);
  2. ACC-LCM-F lens adapter photograph

CCD Line Camera Spectral Response

Application Software GUI

Product specifications are subject to change without prior notice. All prices are FOB California, unless otherwise stated. Please call/email for volume pricing.
