USB2.0 3648-Pixel 16-bit CCD Line Camera with External Trigger
$ 17.85
Customize your product
- Product Details
- Specifications
- Downloads
- Drawings
- Packing List
- Others
- Software
Mightex’s TCN/TCE-1304-U line camera is a cost-effective high-performance B/W line camera, based on a single-line, 3648-pixel CCD chip with USB2.0 (480 Mb/s) interface. CCD line cameras have several advantages over their area-array counterparts, including high optical linear resolution that allows systems developers to use the cameras to capture two-dimensional (2-D) images by moving the object or the CCD perpendicularly to the scan line. TCE-1304-U is a compact line-scan camera ideal for a variety of OEM applications such as industry process control, optical spectroscopy and bio-medical imaging etc.. Setting up the TCE-1304-U line camera is very easy: one simply needs to install the camera’s application software into any PC, and then connect the line camera to the PC using a USB cable. There is no need to install a DAC card or to use an external power supply.
TCN/TCE-1304-UW camera is the window-less version of TCN/TCE-1304-U, with the glass window removed from the image sensor. Therefore, the former is more sensitive to UV and is more suitable for applications that involve coherent light sources.
Features
- USB2.0 interface
- No external power supply required
- Optical integration time adjustable from 0.1ms to 6.5s
- 3648 pixel silicon linear CCD array
- 8μm x 200μm pixel size
- 16-Bit A/D converter
- Scan rate up to 138 scans/second
- External trigger capability
- 4 GPIO pins
- SDK for user applications
- Demo software with GUI
- Compatible to Windows 2000, XP, Vista, 7/8/10
Applications
- Industrial Process Control
- Optical Spectroscopy
Performance Specifications
| Parameter | Specification |
| CCD | Toshiba TCD1304DG |
| Number of Pixels | 3648 |
| Pixel Size | 8μm x 200μm |
| Spectral Range | 300nm to 1050nm 200nm to 1050nm (Windowless version) |
| Pixel Output Clock | 0.5 MHz |
| Data Storage on Camera | 4 Frames |
| ADC Resolution | 16 bits |
| External Trigger | Yes |
| Trigger Cable | ACC-CAM-DIN8 |
| Exposure Time Range | 0.1ms – 6,500ms |
| GPIO | Yes (4 programmable I/O’s) |
| Frame Rate | 138 scans/second* |
| Host Interface | USB 2.0 |
* Frame Rate is dependent on exposure time. When exposure time is set to 0.1ms, the camera can achieve 138 scans/second.
SDK Features
| Operation Systems | Windows 2000, XP, Vista, Windows 7, 8/8.1, and 10 |
| Minimum Requirement | RAM > 64M; Available Hard Disk Space > 10M |
| USB Port | USB2.0 |
| Multiple Cameras | Supported |
| Device Driver | Yes |
| Demo Application | Yes |
| Library Files | Yes (DLL files and Static Library file) |
| Example Codes | Yes (VC++ and Delphi) |
| Frame Attributes* | Exposure Time, Time Stamp, Trigger Event Count, Over Exposure Detection. |
* SDK will provide call back, which will send user Frame data and the related attributes of this frame, the attributes include: Exposure time, Time Stamp, Trigger Event Count and Over Exposure Flag.
Document Downloads:
- USB2.0 CCD Line Camera Datasheet, Enclosed (P/N: TCE-1304-U/UW) (.pdf file, 574KB)
- USB2.0 CCD Line Camera Datasheet, Board-level (P/N: TCN-1304-U/UW) (.pdf file, 156KB)
- CCD line sensor data sheet (Toshiba TCD1304DG) (.pdf file, 449KB)
Mechanical Drawing Downloads:
- USB2.0 CCD Line Camera Installation Drawing, Enclosed (P/N: TCE-1304-U/UW) (.pdf file, 44.6KB)
- USB2.0 CCD Line Camera Installation Drawing, Board-level (P/N: TCN-1304-U/UW) (.pdf file, 48.3KB)
- USB2.0 CCD Line Camera 3D Drawing, Enclosed (P/N: TCE-1304-U/UW) (.stp file, 684KB)
- USB2.0 CCD Line Camera 3D Drawing, Board-level (P/N: TCN-1304-U/UW) (.stp file, 736KB)
Software Download:
- USB2.0 CCD Line Camera Software Package Download (.zip file, 6.18MB), including the latest 64bit SDK
Mechanical Drawing Downloads:
- USB2.0 CCD Line Camera Installation Drawing, Enclosed (P/N: TCE-1304-U/UW) (.pdf file, 44.6KB)
- USB2.0 CCD Line Camera Installation Drawing, Board-level (P/N: TCN-1304-U/UW) (.pdf file, 48.3KB)
- USB2.0 CCD Line Camera 3D Drawing, Enclosed (P/N: TCE-1304-U/UW) (.stp file, 684KB)
- USB2.0 CCD Line Camera 3D Drawing, Board-level (P/N: TCN-1304-U/UW) (.stp file, 736KB)
Standard Packing List:
- 1x CCD Line Camera (w/o an imaging lens)
- 1x USB Cable (Note: Trigger cable ACC-CAM-DIN8 is NOT included and needs to be ordered separately)
- 1x CD (containing User’s Guide, SDK Manual, Windows-based application software with GUI, and example codes in VB, C++ and Delphi)
Software Download:
- USB2.0 CCD Line Camera Software Package Download (.zip file, 6.18MB), including User’s Guide, SDK, Windows-based application software with GUI, and example codes in VB, C++ and Delphi.
CCD Line Camera F-Mount Lens Adapter (P/N: ACC-LCM-F)
- Download ACC-LCM-F installation drawing (.pdf, 51.8kb);
- ACC-LCM-F lens adapter photograph
CCD Line Camera Spectral Response
Application Software GUI
Product specifications are subject to change without prior notice. All prices are FOB California, unless otherwise stated. Please call/email for volume pricing.
