USB2.0 3648-Pixel 16-bit CCD Line Camera with External Trigger

$ 17.85

Step into summer with the adorable Itty Bitty Limited Edition Beige & Flower Double Buckle Sandals. These girls’ summer sandals are a seasonal essential, offering a sophisticated yet playful look with delicate floral details on a versatile beige upper. Perfect for pairing with summer dresses, linen shorts, or casual denim, these sandals provide a high-end aesthetic at an accessible price. Built for both style and ergonomic support, these sandals feature a contoured, suede-textured footbed that cups the heel and supports the arch, ensuring all-day comfort for growing feet. The adjustable matte-finish double buckles allow for a personalized fit, while the secure heel strap with a hidden Velcro closure makes getting ready quick and easy. The shock-absorbing cork-style midsole and flexible rubber outsole offer excellent traction for active summer days. Key Features: •Chic Floral Detail: A timeless two-strap design with charming flower accents. •Ergonomic Support: Molded footbed designed for optimal comfort and arch support. •Secure & Adjustable Fit: Double buckles and an easy-fasten Velcro heel strap. •Durable Construction: Lightweight cork-effect midsole with a non-slip rubber outsole.

Customize your product

  • Product Details
  • Specifications
  • Downloads
  • Drawings
  • Packing List
  • Others
  • Software

Mightex’s TCN/TCE-1304-U line camera is a cost-effective high-performance B/W line camera, based on a single-line, 3648-pixel CCD chip with USB2.0 (480 Mb/s) interface. CCD line cameras have several advantages over their area-array counterparts, including high optical linear resolution that allows systems developers to use the cameras to capture two-dimensional (2-D) images by moving the object or the CCD perpendicularly to the scan line. TCE-1304-U is a compact line-scan camera ideal for a variety of OEM applications such as industry process control, optical spectroscopy and bio-medical imaging etc.. Setting up the TCE-1304-U line camera is very easy: one simply needs to install the camera’s application software into any PC, and then connect the line camera to the PC using a USB cable. There is no need to install a DAC card or to use an external power supply.

TCN/TCE-1304-UW camera is the window-less version of TCN/TCE-1304-U, with the glass window removed from the image sensor. Therefore, the former is more sensitive to UV and is more suitable for applications that involve coherent light sources.

Features

  • USB2.0 interface
  • No external power supply required
  • Optical integration time adjustable from 0.1ms to 6.5s
  • 3648 pixel silicon linear CCD array
  • 8μm x 200μm pixel size
  • 16-Bit A/D converter
  • Scan rate up to 138 scans/second
  • External trigger capability
  • 4 GPIO pins
  • SDK for user applications
  • Demo software with GUI
  • Compatible to Windows 2000, XP, Vista, 7/8/10

Applications

  • Industrial Process Control
  • Optical Spectroscopy

Performance Specifications

ParameterSpecification
CCDToshiba TCD1304DG
Number of Pixels3648
Pixel Size8μm x 200μm
Spectral Range300nm to 1050nm
200nm to 1050nm (Windowless version)
Pixel Output Clock0.5 MHz
Data Storage on Camera4 Frames
ADC Resolution16 bits
External TriggerYes
Trigger CableACC-CAM-DIN8
Exposure Time Range0.1ms – 6,500ms
GPIOYes (4 programmable I/O’s)
Frame Rate138 scans/second*
Host InterfaceUSB 2.0

* Frame Rate is dependent on exposure time. When exposure time is set to 0.1ms, the camera can achieve 138 scans/second.

SDK Features

Operation SystemsWindows 2000, XP, Vista, Windows 7, 8/8.1, and 10
Minimum RequirementRAM > 64M; Available Hard Disk Space > 10M
USB PortUSB2.0
Multiple CamerasSupported
Device DriverYes
Demo ApplicationYes
Library FilesYes (DLL files and Static Library file)
Example CodesYes (VC++ and Delphi)
Frame Attributes*Exposure Time, Time Stamp, Trigger Event Count, Over Exposure Detection.

* SDK will provide call back, which will send user Frame data and the related attributes of this frame, the attributes include: Exposure time, Time Stamp, Trigger Event Count and Over Exposure Flag.



Document Downloads:

Mechanical Drawing Downloads:

Software Download:

Mechanical Drawing Downloads:

Standard Packing List:

  1. 1x CCD Line Camera (w/o an imaging lens)
  2. 1x USB Cable (Note: Trigger cable ACC-CAM-DIN8 is NOT included and needs to be ordered separately)
  3. 1x CD (containing User’s Guide, SDK Manual, Windows-based application software with GUI, and example codes in VB, C++ and Delphi)

Software Download:

CCD Line Camera F-Mount Lens Adapter (P/N: ACC-LCM-F)

  1. Download ACC-LCM-F installation drawing (.pdf, 51.8kb);
  2. ACC-LCM-F lens adapter photograph

CCD Line Camera Spectral Response

Application Software GUI

Product specifications are subject to change without prior notice. All prices are FOB California, unless otherwise stated. Please call/email for volume pricing.
