USB2.0 3648-Pixel 16-bit CCD Line Camera with External Trigger

$ 70.82

There’s nothing quite like slipping into comfortable pyjamas after a long day, and the Lovu Ribbed Winter Pyjama Set is designed to make those moments even better. Made from a soft and comfortable ribbed fabric, this matching lounge set is perfect for cooler weather. The relaxed fit allows for easy movement while providing the warmth and comfort you need for winter evenings, lazy weekends, and slow mornings. Whether you’re enjoying a cup of coffee before the school run, working from home, watching your favourite series, or settling in for the night, this versatile set is designed to keep you feeling comfortable throughout the day. Proudly made in South Africa, each set is crafted with attention to detail and designed to become a favourite part of your winter wardrobe. Why You’ll Love It Soft ribbed fabric for added warmth and comfort Comfortable relaxed fit Matching top and pants set Perfect for lounging, sleeping, and travel Suitable for cooler weather Easy to wear all day long Proudly made in South Africa Optional Extras Customise your pyjama set with optional features such as: Drawstring waistband Side pockets Please only select optional extras if they are not already listed as included in the product description. Fabric & Feel Made from a premium ribbed fabric, this set offers a soft feel with comfortable stretch for everyday wear. The fabric is warm, breathable, and designed to keep you comfortable throughout the colder months. Style It Your Way While designed as sleepwear, many customers love wearing their Ribbed Winter Pyjama Set for relaxing at home, weekend getaways, road trips, and cosy winter mornings. Pair with your favourite slippers, dressing gown, or teddy jacket for extra warmth. Inclusive Sizing At Lovu, we believe every woman deserves clothing that fits beautifully and feels comfortable. Our garments are available in a full range of sizes from XS to 5XL, with custom sizing options available. Whether you’re petite, tall, curvy, or somewhere in between, we’re committed to creating clothing that helps you feel confident and comfortable. Need Help Choosing a Fabric? Visit our fabric options page to learn more about our available fabrics, their feel, stretch, and suitability for different garment styles. Questions Before Ordering? We’re happy to help. Please visit our contact us page if you need assistance with sizing, fabric selection, customisations, or choosing the best option for your needs. Lead Time Please allow 1–10 working days for your garment to be made. During periods of load-shedding or high order volumes, lead times may increase by an additional 2–5 working days. If you require your order by a specific date, please contact us before placing your order. Please Note Colours may vary slightly due to differences in screen settings across devices. plan it

Customize your product

  • Product Details
  • Specifications
  • Downloads
  • Drawings
  • Packing List
  • Others
  • Software

Mightex’s TCN/TCE-1304-U line camera is a cost-effective high-performance B/W line camera, based on a single-line, 3648-pixel CCD chip with USB2.0 (480 Mb/s) interface. CCD line cameras have several advantages over their area-array counterparts, including high optical linear resolution that allows systems developers to use the cameras to capture two-dimensional (2-D) images by moving the object or the CCD perpendicularly to the scan line. TCE-1304-U is a compact line-scan camera ideal for a variety of OEM applications such as industry process control, optical spectroscopy and bio-medical imaging etc.. Setting up the TCE-1304-U line camera is very easy: one simply needs to install the camera’s application software into any PC, and then connect the line camera to the PC using a USB cable. There is no need to install a DAC card or to use an external power supply.

TCN/TCE-1304-UW camera is the window-less version of TCN/TCE-1304-U, with the glass window removed from the image sensor. Therefore, the former is more sensitive to UV and is more suitable for applications that involve coherent light sources.

Features

  • USB2.0 interface
  • No external power supply required
  • Optical integration time adjustable from 0.1ms to 6.5s
  • 3648 pixel silicon linear CCD array
  • 8μm x 200μm pixel size
  • 16-Bit A/D converter
  • Scan rate up to 138 scans/second
  • External trigger capability
  • 4 GPIO pins
  • SDK for user applications
  • Demo software with GUI
  • Compatible to Windows 2000, XP, Vista, 7/8/10

Applications

  • Industrial Process Control
  • Optical Spectroscopy

Performance Specifications

ParameterSpecification
CCDToshiba TCD1304DG
Number of Pixels3648
Pixel Size8μm x 200μm
Spectral Range300nm to 1050nm
200nm to 1050nm (Windowless version)
Pixel Output Clock0.5 MHz
Data Storage on Camera4 Frames
ADC Resolution16 bits
External TriggerYes
Trigger CableACC-CAM-DIN8
Exposure Time Range0.1ms – 6,500ms
GPIOYes (4 programmable I/O’s)
Frame Rate138 scans/second*
Host InterfaceUSB 2.0

* Frame Rate is dependent on exposure time. When exposure time is set to 0.1ms, the camera can achieve 138 scans/second.

SDK Features

Operation SystemsWindows 2000, XP, Vista, Windows 7, 8/8.1, and 10
Minimum RequirementRAM > 64M; Available Hard Disk Space > 10M
USB PortUSB2.0
Multiple CamerasSupported
Device DriverYes
Demo ApplicationYes
Library FilesYes (DLL files and Static Library file)
Example CodesYes (VC++ and Delphi)
Frame Attributes*Exposure Time, Time Stamp, Trigger Event Count, Over Exposure Detection.

* SDK will provide call back, which will send user Frame data and the related attributes of this frame, the attributes include: Exposure time, Time Stamp, Trigger Event Count and Over Exposure Flag.



Document Downloads:

Mechanical Drawing Downloads:

Software Download:

Mechanical Drawing Downloads:

Standard Packing List:

  1. 1x CCD Line Camera (w/o an imaging lens)
  2. 1x USB Cable (Note: Trigger cable ACC-CAM-DIN8 is NOT included and needs to be ordered separately)
  3. 1x CD (containing User’s Guide, SDK Manual, Windows-based application software with GUI, and example codes in VB, C++ and Delphi)

Software Download:

CCD Line Camera F-Mount Lens Adapter (P/N: ACC-LCM-F)

  1. Download ACC-LCM-F installation drawing (.pdf, 51.8kb);
  2. ACC-LCM-F lens adapter photograph

CCD Line Camera Spectral Response

Application Software GUI

Product specifications are subject to change without prior notice. All prices are FOB California, unless otherwise stated. Please call/email for volume pricing.
