USB2.0 3648-Pixel 16-bit CCD Line Camera with External Trigger

$ 70.82

Effortless, feminine and easy to wear, the Ladies Easy Summer Maxi Dress is designed for relaxed elegance and everyday comfort. Featuring a soft gathered neckline with delicate straps, this flowing maxi dress drapes beautifully for a flattering silhouette that feels light and breathable. The elasticated waist creates shape without compromising on comfort, making this the perfect easy throw-on dress for warm days, holidays, brunch dates, special occasions or relaxed evening wear. Its timeless minimalist design makes it incredibly versatile.  This dress can be styled casually with sandals for daytime wear or dress it up with heels and gold accessories for an elevated evening look. Designed with comfort and movement in mind, this maxi dress offers a soft flowing fit that flatters all body shapes beautifully. Proudly made in South Africa, each garment is made to order with attention to detail and quality craftsmanship. Ladies Easy Summer Maxi Dress Features Elegant gathered neckline Soft flowing maxi length Comfortable elasticated waist Lightweight, breathable fabric Relaxed feminine fit Easy pull-on style Comfortable for everyday wear Can be dressed up or down Available in a variety of colours and prints Tall and plus size friendly Proudly made in South Africa Please allow 8–10 working days for your garment to be made. During peak periods and load-shedding schedules, lead times may increase slightly by an additional 2–5 working days. If you require your order by a specific date, please email us before placing your order and we will gladly try assist. We believe beautiful clothing should fit beautifully on every body. This style is available as part of our Tall & Plus Size Collection and can be customised for additional length or adjusted proportions for a more comfortable fit while maintaining our signature effortless aesthetic. Please note that slight variations in exact colour appearance may occur due to device screen settings and lighting. Fabric prints and colour options may rotate depending on fabric availability. plan it

Customize your product

  • Product Details
  • Specifications
  • Downloads
  • Drawings
  • Packing List
  • Others
  • Software

Mightex’s TCN/TCE-1304-U line camera is a cost-effective high-performance B/W line camera, based on a single-line, 3648-pixel CCD chip with USB2.0 (480 Mb/s) interface. CCD line cameras have several advantages over their area-array counterparts, including high optical linear resolution that allows systems developers to use the cameras to capture two-dimensional (2-D) images by moving the object or the CCD perpendicularly to the scan line. TCE-1304-U is a compact line-scan camera ideal for a variety of OEM applications such as industry process control, optical spectroscopy and bio-medical imaging etc.. Setting up the TCE-1304-U line camera is very easy: one simply needs to install the camera’s application software into any PC, and then connect the line camera to the PC using a USB cable. There is no need to install a DAC card or to use an external power supply.

TCN/TCE-1304-UW camera is the window-less version of TCN/TCE-1304-U, with the glass window removed from the image sensor. Therefore, the former is more sensitive to UV and is more suitable for applications that involve coherent light sources.

Features

  • USB2.0 interface
  • No external power supply required
  • Optical integration time adjustable from 0.1ms to 6.5s
  • 3648 pixel silicon linear CCD array
  • 8μm x 200μm pixel size
  • 16-Bit A/D converter
  • Scan rate up to 138 scans/second
  • External trigger capability
  • 4 GPIO pins
  • SDK for user applications
  • Demo software with GUI
  • Compatible to Windows 2000, XP, Vista, 7/8/10

Applications

  • Industrial Process Control
  • Optical Spectroscopy

Performance Specifications

ParameterSpecification
CCDToshiba TCD1304DG
Number of Pixels3648
Pixel Size8μm x 200μm
Spectral Range300nm to 1050nm
200nm to 1050nm (Windowless version)
Pixel Output Clock0.5 MHz
Data Storage on Camera4 Frames
ADC Resolution16 bits
External TriggerYes
Trigger CableACC-CAM-DIN8
Exposure Time Range0.1ms – 6,500ms
GPIOYes (4 programmable I/O’s)
Frame Rate138 scans/second*
Host InterfaceUSB 2.0

* Frame Rate is dependent on exposure time. When exposure time is set to 0.1ms, the camera can achieve 138 scans/second.

SDK Features

Operation SystemsWindows 2000, XP, Vista, Windows 7, 8/8.1, and 10
Minimum RequirementRAM > 64M; Available Hard Disk Space > 10M
USB PortUSB2.0
Multiple CamerasSupported
Device DriverYes
Demo ApplicationYes
Library FilesYes (DLL files and Static Library file)
Example CodesYes (VC++ and Delphi)
Frame Attributes*Exposure Time, Time Stamp, Trigger Event Count, Over Exposure Detection.

* SDK will provide call back, which will send user Frame data and the related attributes of this frame, the attributes include: Exposure time, Time Stamp, Trigger Event Count and Over Exposure Flag.



Document Downloads:

Mechanical Drawing Downloads:

Software Download:

Mechanical Drawing Downloads:

Standard Packing List:

  1. 1x CCD Line Camera (w/o an imaging lens)
  2. 1x USB Cable (Note: Trigger cable ACC-CAM-DIN8 is NOT included and needs to be ordered separately)
  3. 1x CD (containing User’s Guide, SDK Manual, Windows-based application software with GUI, and example codes in VB, C++ and Delphi)

Software Download:

CCD Line Camera F-Mount Lens Adapter (P/N: ACC-LCM-F)

  1. Download ACC-LCM-F installation drawing (.pdf, 51.8kb);
  2. ACC-LCM-F lens adapter photograph

CCD Line Camera Spectral Response

Application Software GUI

Product specifications are subject to change without prior notice. All prices are FOB California, unless otherwise stated. Please call/email for volume pricing.
