USB2.0 3648-Pixel 16-bit CCD Line Camera with External Trigger

$ 70.82

Ladies Classic Thin Strap Jumpsuit – Designed With Your Elegance & Comfort In Mind Enhance your wardrobe options with the Ladies Classic Thin Strap Jumpsuit – a stunning combination of simplicity and sophistication, designed for ultimate comfort without compromising on style. This versatile piece features a flattering halter neck, a ruched neckline, and a button-close back, adding a touch of elegance to your look. Whether you’re relaxing at home or heading out for an evening event, this jumpsuit effortlessly transitions to suit any occasion. Crafted from stretch fabric, this jumpsuit provides a flattering fit, ensuring comfort and freedom of movement. Its non-crease material makes it easy to care for, while the hand-picked, limited edition fabric options add a unique touch to your wardrobe. Available in all sizes, the Ladies Classic Thin Strap Jumpsuit is perfect for any woman who wants a chic, comfortable outfit with a touch of luxury. Product Features: Stretch Fabric: Ensures a comfortable, flattering fit for all body types. Halter Neck: Adds a stylish, sophisticated neckline. Button Neck Tie: Secures with a functional and elegant button detail at the back. Non-Crease Fabric: Perfect for easy maintenance and on-the-go style. Versatile Wear: Ideal for both leisure and dressed-up occasions like work or evening events. Size Inclusive: Available in all sizes to suit women of all shapes. Mommy and Me Sets: Match with your little one for a coordinated look. Proudly Made in South Africa: Designed and crafted with care. Please note: Color variations may appear due to different screen settings, and fabric availability may rotate. All fabric options are exclusive, limited edition, and carefully selected for quality and style. Shipping Details: Please allow 1-10 working days for order processing. Lead times may increase by 2-5 working days depending on load-shedding schedules. If you need your order by a specific date, kindly reach out to us for assistance. Discover your ideal fabric and embrace the effortless elegance of the Ladies Classic Thin Strap Jumpsuit today! We know that every woman is different.  Please have a look at our fabric options to find your ideal fabric option. plan it

Customize your product

  • Product Details
  • Specifications
  • Downloads
  • Drawings
  • Packing List
  • Others
  • Software

Mightex’s TCN/TCE-1304-U line camera is a cost-effective high-performance B/W line camera, based on a single-line, 3648-pixel CCD chip with USB2.0 (480 Mb/s) interface. CCD line cameras have several advantages over their area-array counterparts, including high optical linear resolution that allows systems developers to use the cameras to capture two-dimensional (2-D) images by moving the object or the CCD perpendicularly to the scan line. TCE-1304-U is a compact line-scan camera ideal for a variety of OEM applications such as industry process control, optical spectroscopy and bio-medical imaging etc.. Setting up the TCE-1304-U line camera is very easy: one simply needs to install the camera’s application software into any PC, and then connect the line camera to the PC using a USB cable. There is no need to install a DAC card or to use an external power supply.

TCN/TCE-1304-UW camera is the window-less version of TCN/TCE-1304-U, with the glass window removed from the image sensor. Therefore, the former is more sensitive to UV and is more suitable for applications that involve coherent light sources.

Features

  • USB2.0 interface
  • No external power supply required
  • Optical integration time adjustable from 0.1ms to 6.5s
  • 3648 pixel silicon linear CCD array
  • 8μm x 200μm pixel size
  • 16-Bit A/D converter
  • Scan rate up to 138 scans/second
  • External trigger capability
  • 4 GPIO pins
  • SDK for user applications
  • Demo software with GUI
  • Compatible to Windows 2000, XP, Vista, 7/8/10

Applications

  • Industrial Process Control
  • Optical Spectroscopy

Performance Specifications

ParameterSpecification
CCDToshiba TCD1304DG
Number of Pixels3648
Pixel Size8μm x 200μm
Spectral Range300nm to 1050nm
200nm to 1050nm (Windowless version)
Pixel Output Clock0.5 MHz
Data Storage on Camera4 Frames
ADC Resolution16 bits
External TriggerYes
Trigger CableACC-CAM-DIN8
Exposure Time Range0.1ms – 6,500ms
GPIOYes (4 programmable I/O’s)
Frame Rate138 scans/second*
Host InterfaceUSB 2.0

* Frame Rate is dependent on exposure time. When exposure time is set to 0.1ms, the camera can achieve 138 scans/second.

SDK Features

Operation SystemsWindows 2000, XP, Vista, Windows 7, 8/8.1, and 10
Minimum RequirementRAM > 64M; Available Hard Disk Space > 10M
USB PortUSB2.0
Multiple CamerasSupported
Device DriverYes
Demo ApplicationYes
Library FilesYes (DLL files and Static Library file)
Example CodesYes (VC++ and Delphi)
Frame Attributes*Exposure Time, Time Stamp, Trigger Event Count, Over Exposure Detection.

* SDK will provide call back, which will send user Frame data and the related attributes of this frame, the attributes include: Exposure time, Time Stamp, Trigger Event Count and Over Exposure Flag.



Document Downloads:

Mechanical Drawing Downloads:

Software Download:

Mechanical Drawing Downloads:

Standard Packing List:

  1. 1x CCD Line Camera (w/o an imaging lens)
  2. 1x USB Cable (Note: Trigger cable ACC-CAM-DIN8 is NOT included and needs to be ordered separately)
  3. 1x CD (containing User’s Guide, SDK Manual, Windows-based application software with GUI, and example codes in VB, C++ and Delphi)

Software Download:

CCD Line Camera F-Mount Lens Adapter (P/N: ACC-LCM-F)

  1. Download ACC-LCM-F installation drawing (.pdf, 51.8kb);
  2. ACC-LCM-F lens adapter photograph

CCD Line Camera Spectral Response

Application Software GUI

Product specifications are subject to change without prior notice. All prices are FOB California, unless otherwise stated. Please call/email for volume pricing.
