USB2.0 3648-Pixel 16-bit CCD Line Camera with External Trigger

$ 54.42

Kimono Sleeve Wrap Mini Dress for Any Occasion The Kimono Sleeve Wrap Mini Dress is a stunning, loose-fitting mini dress designed to offer both comfort and style. With its true wrap closure and self-tie belt at the side, this dress effortlessly enhances your silhouette, making it the perfect choice for casual outings or semi-formal occasions. Dolman-style kimono sleeves has relaxed fit around the arms, which ads to the overall comfort and chic aesthetic of this dress. Crafted from luxurious fabrics such as soft, flowing satin, viscose, and imported georgette, this dress guarantees a comfortable and flattering fit. The wrap front creates a flattering shape, while you can choose between short sleeves for a more casual look or elegant long balloon sleeves for a more refined appearance. Whether you’re dressing up for an evening event or keeping it casual for a day out with friends, the Kimono Sleeve Wrap Mini Dress is a versatile wardrobe essential. Kimono Sleeve Wrap Mini Dress Features: Luxurious Fabrics: Crafted from premium materials like satin, viscose, and georgette, providing a smooth, comfortable fit. Stylish Design: The wrap front enhances your silhouette, while the kimono-style sleeves add a unique touch of elegance. Customizable Options: Tailor your dress to your preferences with options for size, fabric, and length to create a perfect fit. Versatile Wear: Ideal for a wide range of occasions, from casual brunches to more semi-formal events. Self-Tie Belt: The adjustable belt allows for a customizable fit that flatters your waistline. Available in Various Sleeve Options: Choose between short sleeves for a casual look or long balloon sleeves for a more formal style. Perfect For: Casual outings like brunch with friends or a day at the park Semi-formal events such as garden parties, cocktails, or date nights Layering for cooler weather with the option of long balloon sleeves Important Notes: Slight colour variations may occur due to different device screens. Fabric options rotate based on availability. All selections are exclusive and limited edition. Lead Time: Please allow 1-10 working days for garment production. During load-shedding, lead times may extend by 2-5 days. If you need your dress by a specific date, please reach out to us for special arrangements. This dress is a timeless and versatile piece perfect for any occasion. Choose your fabric, size, and sleeve option to create the dress that fits your unique style and personality. plan it plan it plan it plan it plan it plan it plan it plan it plan it plan it

Customize your product

  • Product Details
  • Specifications
  • Downloads
  • Drawings
  • Packing List
  • Others
  • Software

Mightex’s TCN/TCE-1304-U line camera is a cost-effective high-performance B/W line camera, based on a single-line, 3648-pixel CCD chip with USB2.0 (480 Mb/s) interface. CCD line cameras have several advantages over their area-array counterparts, including high optical linear resolution that allows systems developers to use the cameras to capture two-dimensional (2-D) images by moving the object or the CCD perpendicularly to the scan line. TCE-1304-U is a compact line-scan camera ideal for a variety of OEM applications such as industry process control, optical spectroscopy and bio-medical imaging etc.. Setting up the TCE-1304-U line camera is very easy: one simply needs to install the camera’s application software into any PC, and then connect the line camera to the PC using a USB cable. There is no need to install a DAC card or to use an external power supply.

TCN/TCE-1304-UW camera is the window-less version of TCN/TCE-1304-U, with the glass window removed from the image sensor. Therefore, the former is more sensitive to UV and is more suitable for applications that involve coherent light sources.

Features

  • USB2.0 interface
  • No external power supply required
  • Optical integration time adjustable from 0.1ms to 6.5s
  • 3648 pixel silicon linear CCD array
  • 8μm x 200μm pixel size
  • 16-Bit A/D converter
  • Scan rate up to 138 scans/second
  • External trigger capability
  • 4 GPIO pins
  • SDK for user applications
  • Demo software with GUI
  • Compatible to Windows 2000, XP, Vista, 7/8/10

Applications

  • Industrial Process Control
  • Optical Spectroscopy

Performance Specifications

ParameterSpecification
CCDToshiba TCD1304DG
Number of Pixels3648
Pixel Size8μm x 200μm
Spectral Range300nm to 1050nm
200nm to 1050nm (Windowless version)
Pixel Output Clock0.5 MHz
Data Storage on Camera4 Frames
ADC Resolution16 bits
External TriggerYes
Trigger CableACC-CAM-DIN8
Exposure Time Range0.1ms – 6,500ms
GPIOYes (4 programmable I/O’s)
Frame Rate138 scans/second*
Host InterfaceUSB 2.0

* Frame Rate is dependent on exposure time. When exposure time is set to 0.1ms, the camera can achieve 138 scans/second.

SDK Features

Operation SystemsWindows 2000, XP, Vista, Windows 7, 8/8.1, and 10
Minimum RequirementRAM > 64M; Available Hard Disk Space > 10M
USB PortUSB2.0
Multiple CamerasSupported
Device DriverYes
Demo ApplicationYes
Library FilesYes (DLL files and Static Library file)
Example CodesYes (VC++ and Delphi)
Frame Attributes*Exposure Time, Time Stamp, Trigger Event Count, Over Exposure Detection.

* SDK will provide call back, which will send user Frame data and the related attributes of this frame, the attributes include: Exposure time, Time Stamp, Trigger Event Count and Over Exposure Flag.



Document Downloads:

Mechanical Drawing Downloads:

Software Download:

Mechanical Drawing Downloads:

Standard Packing List:

  1. 1x CCD Line Camera (w/o an imaging lens)
  2. 1x USB Cable (Note: Trigger cable ACC-CAM-DIN8 is NOT included and needs to be ordered separately)
  3. 1x CD (containing User’s Guide, SDK Manual, Windows-based application software with GUI, and example codes in VB, C++ and Delphi)

Software Download:

CCD Line Camera F-Mount Lens Adapter (P/N: ACC-LCM-F)

  1. Download ACC-LCM-F installation drawing (.pdf, 51.8kb);
  2. ACC-LCM-F lens adapter photograph

CCD Line Camera Spectral Response

Application Software GUI

Product specifications are subject to change without prior notice. All prices are FOB California, unless otherwise stated. Please call/email for volume pricing.
