USB2.0 3648-Pixel 16-bit CCD Line Camera with External Trigger

$ 70.82

The Multiway Infinity Mini Dress needs no introduction. This garment is suitable for a day or evening event and adapts effortlessly to a variety of styles.  With options for batwing sleeves, halter necks, tank straps, twist styles, and more you can create a different look for every occasion .  The Multiway Infinity Convertable dress is a popular option for Bridesmaid dresses. The Multiway Infinity Mini Dress Highlights Bandeau Optional: Enjoy added coverage with a matching bandeau, allowing you to style the dress to your comfort level without sacrificing elegance. Bridesmaids: This modern multiway design offers bridesmaids the freedom to customise their look, ensuring a cohesive yet personal style that everyone will love. Comfort Meets Elegance: Crafted from soft, breathable, and stretchy fabric, our infinity dress is both comfortable and chic. Its wrinkle-resistant nature makes it the ideal travel companion for busy women. Multiway Infinity Mini Dress Features 2 M Straps: Style your dress in many ways. Quality Fabric: Available in a variety of colours and patterns. Comfortable Top Straps: Can be tied in various styles to change the appearance of the dress. Slight Overlap on Straps: Provides extra bust coverage. Custom Options: Choose from various fabric colours and heights to create your ideal dress. Made in South Africa: Crafted with care and attention to detail. Important Notes For group orders, let us know if you’re ordering as a group of bridesmaids to ensure color consistency. This item is available as a mommy and me set please have a look at our kids add-on options here Please allow 1-10 working days for garments to be made.  This lead time might increase slightly within 2 – 5 working days depending on load-shedding schedules.  Please let us know if you need your order at a specific date. We have compiled a guide to fabric types available here.  Please contact us for guidance or assistance should you need any additional information to find your perfect fabric option.  Please note that slight differences in EXACT colour appearance might be due to different device screens. Fabric options do rotate due to availability.  The options listed are the options available.   plan it plan it plan it

Customize your product

  • Product Details
  • Specifications
  • Downloads
  • Drawings
  • Packing List
  • Others
  • Software

Mightex’s TCN/TCE-1304-U line camera is a cost-effective high-performance B/W line camera, based on a single-line, 3648-pixel CCD chip with USB2.0 (480 Mb/s) interface. CCD line cameras have several advantages over their area-array counterparts, including high optical linear resolution that allows systems developers to use the cameras to capture two-dimensional (2-D) images by moving the object or the CCD perpendicularly to the scan line. TCE-1304-U is a compact line-scan camera ideal for a variety of OEM applications such as industry process control, optical spectroscopy and bio-medical imaging etc.. Setting up the TCE-1304-U line camera is very easy: one simply needs to install the camera’s application software into any PC, and then connect the line camera to the PC using a USB cable. There is no need to install a DAC card or to use an external power supply.

TCN/TCE-1304-UW camera is the window-less version of TCN/TCE-1304-U, with the glass window removed from the image sensor. Therefore, the former is more sensitive to UV and is more suitable for applications that involve coherent light sources.

Features

  • USB2.0 interface
  • No external power supply required
  • Optical integration time adjustable from 0.1ms to 6.5s
  • 3648 pixel silicon linear CCD array
  • 8μm x 200μm pixel size
  • 16-Bit A/D converter
  • Scan rate up to 138 scans/second
  • External trigger capability
  • 4 GPIO pins
  • SDK for user applications
  • Demo software with GUI
  • Compatible to Windows 2000, XP, Vista, 7/8/10

Applications

  • Industrial Process Control
  • Optical Spectroscopy

Performance Specifications

ParameterSpecification
CCDToshiba TCD1304DG
Number of Pixels3648
Pixel Size8μm x 200μm
Spectral Range300nm to 1050nm
200nm to 1050nm (Windowless version)
Pixel Output Clock0.5 MHz
Data Storage on Camera4 Frames
ADC Resolution16 bits
External TriggerYes
Trigger CableACC-CAM-DIN8
Exposure Time Range0.1ms – 6,500ms
GPIOYes (4 programmable I/O’s)
Frame Rate138 scans/second*
Host InterfaceUSB 2.0

* Frame Rate is dependent on exposure time. When exposure time is set to 0.1ms, the camera can achieve 138 scans/second.

SDK Features

Operation SystemsWindows 2000, XP, Vista, Windows 7, 8/8.1, and 10
Minimum RequirementRAM > 64M; Available Hard Disk Space > 10M
USB PortUSB2.0
Multiple CamerasSupported
Device DriverYes
Demo ApplicationYes
Library FilesYes (DLL files and Static Library file)
Example CodesYes (VC++ and Delphi)
Frame Attributes*Exposure Time, Time Stamp, Trigger Event Count, Over Exposure Detection.

* SDK will provide call back, which will send user Frame data and the related attributes of this frame, the attributes include: Exposure time, Time Stamp, Trigger Event Count and Over Exposure Flag.



Document Downloads:

Mechanical Drawing Downloads:

Software Download:

Mechanical Drawing Downloads:

Standard Packing List:

  1. 1x CCD Line Camera (w/o an imaging lens)
  2. 1x USB Cable (Note: Trigger cable ACC-CAM-DIN8 is NOT included and needs to be ordered separately)
  3. 1x CD (containing User’s Guide, SDK Manual, Windows-based application software with GUI, and example codes in VB, C++ and Delphi)

Software Download:

CCD Line Camera F-Mount Lens Adapter (P/N: ACC-LCM-F)

  1. Download ACC-LCM-F installation drawing (.pdf, 51.8kb);
  2. ACC-LCM-F lens adapter photograph

CCD Line Camera Spectral Response

Application Software GUI

Product specifications are subject to change without prior notice. All prices are FOB California, unless otherwise stated. Please call/email for volume pricing.
