USB2.0 3648-Pixel 16-bit CCD Line Camera with External Trigger

$ 70.82

Effortlessly elegant and endlessly versatile, the Ladies Easy Summer Halter-Neck Jumpsuit is designed for comfort without compromising on style. Featuring a flattering halter neckline with adjustable neck ties, a relaxed wide-leg fit and soft stretch fabric, this easy-to-wear jumpsuit can be styled casually for daytime wear or dressed up beautifully for evenings, events or workwear. Proudly made in South Africa. The Ladies Easy Summer Halter-Neck Jumpsuit is the perfect blend of effortless comfort and timeless elegance. Designed with a flattering draped halter neckline and adjustable neck ties that fasten at the back, this jumpsuit creates a feminine silhouette while remaining relaxed and comfortable enough for everyday wear. Crafted from soft stretch fabric with a beautiful drape, the Easy Summer Jumpsuit features a loose-flowing wide-leg fit, elasticated waist and lightweight non-crease fabric, making it ideal for travel, holidays, workwear or elegant everyday styling. Its minimalist silhouette allows it to transition seamlessly from casual daytime wear to elevated evening looks simply by changing accessories and shoes. Style it with sandals for relaxed summer days or dress it up with heels and jewellery for a sophisticated evening outfit. Proudly made in South Africa, each piece is thoughtfully made in limited edition fabrics carefully selected for comfort, quality and effortless style. Ladies Easy Summer Halter-Neck Jumpsuit Features Elegant halter-neck design Adjustable neck tie fastening at the back Soft stretch fabric with beautiful drape Relaxed wide-leg fit Elasticated waist for comfort Lightweight non-crease fabric Comfortable and breathable Can be styled casually or dressed up Suitable for leisurewear, workwear or evening wear Available in all sizes Proudly made in South Africa Tall & Plus Size Friendly At Lovu, we believe beautiful clothing should fit beautifully on every body. This jumpsuit can be customised for tall and plus size fits as part of our Tall & Plus Size Collection. From added length adjustments to more comfortable sizing and proportions, each garment is thoughtfully made to offer a flattering and comfortable fit while maintaining our signature effortless aesthetic. Production Lead Time Please allow 1–10 working days for the Ladies Easy Summer Halter-Neck Jumpsuit to be made. Depending on load-shedding schedules and production volumes, this lead time might increase slightly within 2–5 additional working days. If you require your order by a specific date, please let us know in advance and we will gladly try to accommodate your request. Important Notes Please note that slight differences in exact colour appearance may occur due to different device screens and lighting. Fabric options rotate regularly based on availability. The listed fabric options are the currently available selections. All of our fabrics are carefully hand-picked, exclusive and available in limited editions. plan it

Customize your product

  • Product Details
  • Specifications
  • Downloads
  • Drawings
  • Packing List
  • Others
  • Software

Mightex’s TCN/TCE-1304-U line camera is a cost-effective high-performance B/W line camera, based on a single-line, 3648-pixel CCD chip with USB2.0 (480 Mb/s) interface. CCD line cameras have several advantages over their area-array counterparts, including high optical linear resolution that allows systems developers to use the cameras to capture two-dimensional (2-D) images by moving the object or the CCD perpendicularly to the scan line. TCE-1304-U is a compact line-scan camera ideal for a variety of OEM applications such as industry process control, optical spectroscopy and bio-medical imaging etc.. Setting up the TCE-1304-U line camera is very easy: one simply needs to install the camera’s application software into any PC, and then connect the line camera to the PC using a USB cable. There is no need to install a DAC card or to use an external power supply.

TCN/TCE-1304-UW camera is the window-less version of TCN/TCE-1304-U, with the glass window removed from the image sensor. Therefore, the former is more sensitive to UV and is more suitable for applications that involve coherent light sources.

Features

  • USB2.0 interface
  • No external power supply required
  • Optical integration time adjustable from 0.1ms to 6.5s
  • 3648 pixel silicon linear CCD array
  • 8μm x 200μm pixel size
  • 16-Bit A/D converter
  • Scan rate up to 138 scans/second
  • External trigger capability
  • 4 GPIO pins
  • SDK for user applications
  • Demo software with GUI
  • Compatible to Windows 2000, XP, Vista, 7/8/10

Applications

  • Industrial Process Control
  • Optical Spectroscopy

Performance Specifications

ParameterSpecification
CCDToshiba TCD1304DG
Number of Pixels3648
Pixel Size8μm x 200μm
Spectral Range300nm to 1050nm
200nm to 1050nm (Windowless version)
Pixel Output Clock0.5 MHz
Data Storage on Camera4 Frames
ADC Resolution16 bits
External TriggerYes
Trigger CableACC-CAM-DIN8
Exposure Time Range0.1ms – 6,500ms
GPIOYes (4 programmable I/O’s)
Frame Rate138 scans/second*
Host InterfaceUSB 2.0

* Frame Rate is dependent on exposure time. When exposure time is set to 0.1ms, the camera can achieve 138 scans/second.

SDK Features

Operation SystemsWindows 2000, XP, Vista, Windows 7, 8/8.1, and 10
Minimum RequirementRAM > 64M; Available Hard Disk Space > 10M
USB PortUSB2.0
Multiple CamerasSupported
Device DriverYes
Demo ApplicationYes
Library FilesYes (DLL files and Static Library file)
Example CodesYes (VC++ and Delphi)
Frame Attributes*Exposure Time, Time Stamp, Trigger Event Count, Over Exposure Detection.

* SDK will provide call back, which will send user Frame data and the related attributes of this frame, the attributes include: Exposure time, Time Stamp, Trigger Event Count and Over Exposure Flag.



Document Downloads:

Mechanical Drawing Downloads:

Software Download:

Mechanical Drawing Downloads:

Standard Packing List:

  1. 1x CCD Line Camera (w/o an imaging lens)
  2. 1x USB Cable (Note: Trigger cable ACC-CAM-DIN8 is NOT included and needs to be ordered separately)
  3. 1x CD (containing User’s Guide, SDK Manual, Windows-based application software with GUI, and example codes in VB, C++ and Delphi)

Software Download:

CCD Line Camera F-Mount Lens Adapter (P/N: ACC-LCM-F)

  1. Download ACC-LCM-F installation drawing (.pdf, 51.8kb);
  2. ACC-LCM-F lens adapter photograph

CCD Line Camera Spectral Response

Application Software GUI

Product specifications are subject to change without prior notice. All prices are FOB California, unless otherwise stated. Please call/email for volume pricing.
