USB2.0 3648-Pixel 16-bit CCD Line Camera with External Trigger

$ 19.04

Dress your little ocean dreamer in the ultimate summer look! This enchanting coastal sundress features an all-over pastel seashell, starfish, and coral print set against a soft sandy backdrop with a turquoise ocean shoreline hemline. Detailed with a stretchy smocked bodice, fluttering ruffle straps, and sweet dusty pink bows, it’s the perfect boutique dress for beach vacations, summer parties, and sunny strolls Magical Under-the-Sea Coastal Style Bring the beauty of the seashore straight to her wardrobe. As showcased, this gorgeous summer dress features a vibrant, whimsical underwater illustration packed with intricately detailed seashells, bright starfish, and colorful coral reefs. The bottom tier beautifully transitions into a turquoise ocean wave design dotted with tiny sailboats, creating a picture-perfect resort aesthetic. Comfortable, Stretchy Fit for All-Day Play Beautifully designed with everyday comfort in mind, this dress features a fully elasticated, smocked bodice that stretches gently to accommodate growing toddlers and girls while keeping its shape. The soft, breathable fabric allows for effortless movement, making it as comfortable as it is stunning. The shoulder straps boast playful, double-layered ruffles that frame the face beautifully. Accenting the front of the straps are two sweet, structured dusty pink fabric bows that add the perfect high-end, boutique touch to the square neckline. Key Features Whimsical Ocean Print: Features a detailed seashore pattern with seashells, starfish, coral, and a turquoise ocean hemline. Grow-With-Me Comfort: Stretchy smocked chest bodice provides a secure yet flexible fit for active wear. Boutique Accents: Sweet, contrasting dusty pink bows attached at the base of the straps Fluttering Details: Gorgeous ruffle sleeve straps and a flowing ruffled bottom hem for a classic twirl-worthy silhouette. Perfect Summer Styling: Lightweight, breathable fabric that is ideal for hot summer days, beach vacations, and family portraits.

Customize your product

  • Product Details
  • Specifications
  • Downloads
  • Drawings
  • Packing List
  • Others
  • Software

Mightex’s TCN/TCE-1304-U line camera is a cost-effective high-performance B/W line camera, based on a single-line, 3648-pixel CCD chip with USB2.0 (480 Mb/s) interface. CCD line cameras have several advantages over their area-array counterparts, including high optical linear resolution that allows systems developers to use the cameras to capture two-dimensional (2-D) images by moving the object or the CCD perpendicularly to the scan line. TCE-1304-U is a compact line-scan camera ideal for a variety of OEM applications such as industry process control, optical spectroscopy and bio-medical imaging etc.. Setting up the TCE-1304-U line camera is very easy: one simply needs to install the camera’s application software into any PC, and then connect the line camera to the PC using a USB cable. There is no need to install a DAC card or to use an external power supply.

TCN/TCE-1304-UW camera is the window-less version of TCN/TCE-1304-U, with the glass window removed from the image sensor. Therefore, the former is more sensitive to UV and is more suitable for applications that involve coherent light sources.

Features

  • USB2.0 interface
  • No external power supply required
  • Optical integration time adjustable from 0.1ms to 6.5s
  • 3648 pixel silicon linear CCD array
  • 8μm x 200μm pixel size
  • 16-Bit A/D converter
  • Scan rate up to 138 scans/second
  • External trigger capability
  • 4 GPIO pins
  • SDK for user applications
  • Demo software with GUI
  • Compatible to Windows 2000, XP, Vista, 7/8/10

Applications

  • Industrial Process Control
  • Optical Spectroscopy

Performance Specifications

ParameterSpecification
CCDToshiba TCD1304DG
Number of Pixels3648
Pixel Size8μm x 200μm
Spectral Range300nm to 1050nm
200nm to 1050nm (Windowless version)
Pixel Output Clock0.5 MHz
Data Storage on Camera4 Frames
ADC Resolution16 bits
External TriggerYes
Trigger CableACC-CAM-DIN8
Exposure Time Range0.1ms – 6,500ms
GPIOYes (4 programmable I/O’s)
Frame Rate138 scans/second*
Host InterfaceUSB 2.0

* Frame Rate is dependent on exposure time. When exposure time is set to 0.1ms, the camera can achieve 138 scans/second.

SDK Features

Operation SystemsWindows 2000, XP, Vista, Windows 7, 8/8.1, and 10
Minimum RequirementRAM > 64M; Available Hard Disk Space > 10M
USB PortUSB2.0
Multiple CamerasSupported
Device DriverYes
Demo ApplicationYes
Library FilesYes (DLL files and Static Library file)
Example CodesYes (VC++ and Delphi)
Frame Attributes*Exposure Time, Time Stamp, Trigger Event Count, Over Exposure Detection.

* SDK will provide call back, which will send user Frame data and the related attributes of this frame, the attributes include: Exposure time, Time Stamp, Trigger Event Count and Over Exposure Flag.



Document Downloads:

Mechanical Drawing Downloads:

Software Download:

Mechanical Drawing Downloads:

Standard Packing List:

  1. 1x CCD Line Camera (w/o an imaging lens)
  2. 1x USB Cable (Note: Trigger cable ACC-CAM-DIN8 is NOT included and needs to be ordered separately)
  3. 1x CD (containing User’s Guide, SDK Manual, Windows-based application software with GUI, and example codes in VB, C++ and Delphi)

Software Download:

CCD Line Camera F-Mount Lens Adapter (P/N: ACC-LCM-F)

  1. Download ACC-LCM-F installation drawing (.pdf, 51.8kb);
  2. ACC-LCM-F lens adapter photograph

CCD Line Camera Spectral Response

Application Software GUI

Product specifications are subject to change without prior notice. All prices are FOB California, unless otherwise stated. Please call/email for volume pricing.
