Products / Bows / Electrical USB2.0 3648-Pixel 16-bit CCD Line Camera with External Trigger

USB2.0 3648-Pixel 16-bit CCD Line Camera with External Trigger

$ 70.82

Turn every moment into a picture-perfect memory with our Satin Flower Girl Multiway Infinity Dress — a timeless and versatile piece crafted for girls of all ages. Proudly made in South Africa, this dress is designed to celebrate special occasions in style and comfort. Whether you’re planning a wedding, photoshoot, or a mommy and me matching set, this multiway dress offers unmatched elegance with a twist of creativity. The soft satin fabric delivers a luxurious sheen, while the elastic waistband ensures a secure and comfortable fit for growing girls. Thanks to its unique multiway wrap design, this dress can be styled in countless ways — from classic halter to one-shoulder or criss-cross back — making it perfect for flower girls, junior bridesmaids, birthday parties, or any formal event. It’s a reusable, adjustable dress that grows with your little one and adapts to any dress code or theme. Features: Made in South Africa with care and attention to detail Satin finish for a luxurious, photo-ready look Multiway design: wrap and tie in countless styles Elastic waist for comfort and flexibility Suitable for girls ages 1–14 Perfect for weddings, photoshoots, parties, or matching sets Available in a wide range of vibrant and pastel colours Ideal for coordinated bridal parties and mommy & me outfits Why You’ll Love It: This is more than just a flower girl dress — it’s a keepsake. With endless styling options, your child can wear it again and again in different ways. It’s not only beautiful but also practical for growing girls. Important Notes Group Orders: If you’re ordering as part of a bridesmaid group, please let us know at checkout or via message. This ensures we match all garments from the same fabric batch for perfect colour consistency. Mommy & Me Option: This item is also available as a coordinated Flower Girl/Mommy and Me set. Production Time: Each garment is made to order. Please allow 1–10 working days for production. Lead times may extend by an additional 2–5 working days depending on load-shedding schedules. If you need your order by a specific date, kindly let us know in advance so we can accommodate your timeline. Fabric Options: We offer a variety of fabric types, and a complete guide is available here. If you need help selecting the best fabric for your needs, feel free to reach out to us for personalized assistance. Please note that slight variations in color may occur due to differences in screen settings. Fabric availability may also change from time to time; all listed options are currently in stock.

Customize your product

  • Product Details
  • Specifications
  • Downloads
  • Drawings
  • Packing List
  • Others
  • Software

Mightex’s TCN/TCE-1304-U line camera is a cost-effective high-performance B/W line camera, based on a single-line, 3648-pixel CCD chip with USB2.0 (480 Mb/s) interface. CCD line cameras have several advantages over their area-array counterparts, including high optical linear resolution that allows systems developers to use the cameras to capture two-dimensional (2-D) images by moving the object or the CCD perpendicularly to the scan line. TCE-1304-U is a compact line-scan camera ideal for a variety of OEM applications such as industry process control, optical spectroscopy and bio-medical imaging etc.. Setting up the TCE-1304-U line camera is very easy: one simply needs to install the camera’s application software into any PC, and then connect the line camera to the PC using a USB cable. There is no need to install a DAC card or to use an external power supply.

TCN/TCE-1304-UW camera is the window-less version of TCN/TCE-1304-U, with the glass window removed from the image sensor. Therefore, the former is more sensitive to UV and is more suitable for applications that involve coherent light sources.

Features

  • USB2.0 interface
  • No external power supply required
  • Optical integration time adjustable from 0.1ms to 6.5s
  • 3648 pixel silicon linear CCD array
  • 8μm x 200μm pixel size
  • 16-Bit A/D converter
  • Scan rate up to 138 scans/second
  • External trigger capability
  • 4 GPIO pins
  • SDK for user applications
  • Demo software with GUI
  • Compatible to Windows 2000, XP, Vista, 7/8/10

Applications

  • Industrial Process Control
  • Optical Spectroscopy

Performance Specifications

ParameterSpecification
CCDToshiba TCD1304DG
Number of Pixels3648
Pixel Size8μm x 200μm
Spectral Range300nm to 1050nm
200nm to 1050nm (Windowless version)
Pixel Output Clock0.5 MHz
Data Storage on Camera4 Frames
ADC Resolution16 bits
External TriggerYes
Trigger CableACC-CAM-DIN8
Exposure Time Range0.1ms – 6,500ms
GPIOYes (4 programmable I/O’s)
Frame Rate138 scans/second*
Host InterfaceUSB 2.0

* Frame Rate is dependent on exposure time. When exposure time is set to 0.1ms, the camera can achieve 138 scans/second.

SDK Features

Operation SystemsWindows 2000, XP, Vista, Windows 7, 8/8.1, and 10
Minimum RequirementRAM > 64M; Available Hard Disk Space > 10M
USB PortUSB2.0
Multiple CamerasSupported
Device DriverYes
Demo ApplicationYes
Library FilesYes (DLL files and Static Library file)
Example CodesYes (VC++ and Delphi)
Frame Attributes*Exposure Time, Time Stamp, Trigger Event Count, Over Exposure Detection.

* SDK will provide call back, which will send user Frame data and the related attributes of this frame, the attributes include: Exposure time, Time Stamp, Trigger Event Count and Over Exposure Flag.



Document Downloads:

Mechanical Drawing Downloads:

Software Download:

Mechanical Drawing Downloads:

Standard Packing List:

  1. 1x CCD Line Camera (w/o an imaging lens)
  2. 1x USB Cable (Note: Trigger cable ACC-CAM-DIN8 is NOT included and needs to be ordered separately)
  3. 1x CD (containing User’s Guide, SDK Manual, Windows-based application software with GUI, and example codes in VB, C++ and Delphi)

Software Download:

CCD Line Camera F-Mount Lens Adapter (P/N: ACC-LCM-F)

  1. Download ACC-LCM-F installation drawing (.pdf, 51.8kb);
  2. ACC-LCM-F lens adapter photograph

CCD Line Camera Spectral Response

Application Software GUI

Product specifications are subject to change without prior notice. All prices are FOB California, unless otherwise stated. Please call/email for volume pricing.
