USB2.0 3648-Pixel 16-bit CCD Line Camera with External Trigger

$ 54.42

Refined and easy to wear, the Draped Dolman Sleeve Bubble Hem Top is a wardrobe essential that blends comfort with contemporary style. Proudly made in South Africa, this top features a soft, draped silhouette with loose dolman sleeves and a gathered bubble hem that flatters a variety of body shapes. Crafted from high-quality stretch fabric, the top provides breathability, flexibility, and all-day comfort. Its minimalist design and clean finish make it suitable for both casual and more polished outfits. Whether paired with tailored pants, denim, or a skirt, this draped dolman sleeve bubble hem top effortlessly elevates your everyday style. Key Features: Designed and made in South Africa Draped dolman sleeves for a relaxed, elegant shape Flattering bubble hem for a softly structured silhouette Comfortable stretch fabric that moves with you Double Layer Versatile design for both casual and semi-formal occasions A must-have for women who value both fashion and function, this top is perfect for transitioning between seasons and occasions with ease. Perfect For: Casual outings, brunches, or shopping trips Layering with jackets or cardigans during cooler weather Transitioning from day to night with ease Important Notes Production Time: Each garment is made to order. Please allow 1–10 working days for production. Lead times may extend by an additional 2–5 working days depending on load-shedding schedules. If you need your order by a specific date, kindly let us know in advance so we can accommodate your timeline. Fabric Options: We offer a variety of fabric types, and a complete guide is available here. If you need help selecting the best fabric for your needs, feel free to reach out to us for personalized assistance. Please note that slight variations in color may occur due to differences in screen settings. Fabric availability may also change from time to time; all listed options are currently in stock. Elevate your wardrobe with the Ladies Bubble Hem Wrap Top – a perfect blend of comfort, style, and versatility for any occasion! plan it plan it plan it plan it plan it

Customize your product

  • Product Details
  • Specifications
  • Downloads
  • Drawings
  • Packing List
  • Others
  • Software

Mightex’s TCN/TCE-1304-U line camera is a cost-effective high-performance B/W line camera, based on a single-line, 3648-pixel CCD chip with USB2.0 (480 Mb/s) interface. CCD line cameras have several advantages over their area-array counterparts, including high optical linear resolution that allows systems developers to use the cameras to capture two-dimensional (2-D) images by moving the object or the CCD perpendicularly to the scan line. TCE-1304-U is a compact line-scan camera ideal for a variety of OEM applications such as industry process control, optical spectroscopy and bio-medical imaging etc.. Setting up the TCE-1304-U line camera is very easy: one simply needs to install the camera’s application software into any PC, and then connect the line camera to the PC using a USB cable. There is no need to install a DAC card or to use an external power supply.

TCN/TCE-1304-UW camera is the window-less version of TCN/TCE-1304-U, with the glass window removed from the image sensor. Therefore, the former is more sensitive to UV and is more suitable for applications that involve coherent light sources.

Features

  • USB2.0 interface
  • No external power supply required
  • Optical integration time adjustable from 0.1ms to 6.5s
  • 3648 pixel silicon linear CCD array
  • 8μm x 200μm pixel size
  • 16-Bit A/D converter
  • Scan rate up to 138 scans/second
  • External trigger capability
  • 4 GPIO pins
  • SDK for user applications
  • Demo software with GUI
  • Compatible to Windows 2000, XP, Vista, 7/8/10

Applications

  • Industrial Process Control
  • Optical Spectroscopy

Performance Specifications

ParameterSpecification
CCDToshiba TCD1304DG
Number of Pixels3648
Pixel Size8μm x 200μm
Spectral Range300nm to 1050nm
200nm to 1050nm (Windowless version)
Pixel Output Clock0.5 MHz
Data Storage on Camera4 Frames
ADC Resolution16 bits
External TriggerYes
Trigger CableACC-CAM-DIN8
Exposure Time Range0.1ms – 6,500ms
GPIOYes (4 programmable I/O’s)
Frame Rate138 scans/second*
Host InterfaceUSB 2.0

* Frame Rate is dependent on exposure time. When exposure time is set to 0.1ms, the camera can achieve 138 scans/second.

SDK Features

Operation SystemsWindows 2000, XP, Vista, Windows 7, 8/8.1, and 10
Minimum RequirementRAM > 64M; Available Hard Disk Space > 10M
USB PortUSB2.0
Multiple CamerasSupported
Device DriverYes
Demo ApplicationYes
Library FilesYes (DLL files and Static Library file)
Example CodesYes (VC++ and Delphi)
Frame Attributes*Exposure Time, Time Stamp, Trigger Event Count, Over Exposure Detection.

* SDK will provide call back, which will send user Frame data and the related attributes of this frame, the attributes include: Exposure time, Time Stamp, Trigger Event Count and Over Exposure Flag.



Document Downloads:

Mechanical Drawing Downloads:

Software Download:

Mechanical Drawing Downloads:

Standard Packing List:

  1. 1x CCD Line Camera (w/o an imaging lens)
  2. 1x USB Cable (Note: Trigger cable ACC-CAM-DIN8 is NOT included and needs to be ordered separately)
  3. 1x CD (containing User’s Guide, SDK Manual, Windows-based application software with GUI, and example codes in VB, C++ and Delphi)

Software Download:

CCD Line Camera F-Mount Lens Adapter (P/N: ACC-LCM-F)

  1. Download ACC-LCM-F installation drawing (.pdf, 51.8kb);
  2. ACC-LCM-F lens adapter photograph

CCD Line Camera Spectral Response

Application Software GUI

Product specifications are subject to change without prior notice. All prices are FOB California, unless otherwise stated. Please call/email for volume pricing.
