USB2.0 3648-Pixel 16-bit CCD Line Camera with External Trigger

$ 92.70

The Lantern Sleeve Front Twist Maxi is a timeless, feminine silhouette designed to flatter while offering comfort and versatility. Crafted with a soft, fluid drape, this maxi dress features a signature front twist detail that gently defines the waist without the need for structured bands, creating a naturally elegant shape. The lantern-style sleeves add volume and softness, balancing the fitted bodice with a relaxed, flowing skirt that falls gracefully to ankle length. A subtle front slit enhances movement while maintaining a polished, occasion-ready finish. Designed for both day and evening wear, this piece transitions seamlessly from special occasions to refined everyday styling. The clean construction and minimal detailing allow the fabric and silhouette to take centre stage. Perfect for weddings, events, bridesmaids, or elevated everyday wear, this dress embodies a modern, effortless aesthetic. Key Features Front twist detail for a flattering, softly defined waist Lantern sleeves with gentle volume Ankle-length maxi silhouette (designed to sit just above the shoes) Subtle front slit for ease of movement Lightweight, breathable fabric with fluid drape Suitable for occasion wear, bridesmaids, and events Proudly made in South Africa ���� Fabric & Fit Fabric: selected stretch fabric option (as per dropdown) Fit: Fitted through the bodice with a relaxed skirt Length: Maxi (ankle length) Customisations available on request Styling Suggestions Pair with minimal heels and delicate jewellery for an elevated look, or dress down with flats for a more relaxed, effortless feel. Ideal for both structured occasions and soft, romantic settings. Fabric Options: Please refer to our fabric guide for details on available options, and contact us for any assistance in choosing the best fabric for your needs. Note: Due to varying device screens, the actual colour of the fabric may appear slightly different from the images. Fabric availability may rotate, and we will offer the options that are currently available. Lead Time: Please allow 1-10 working days for garment creation. Lead time may vary slightly due to scheduling or load-shedding. If you need your order by a specific date, please let us know. Add this versatile and stylish piece to your wardrobe today – perfect for any occasion, any time of the year! plan it plan it plan it plan it plan it

Customize your product

  • Product Details
  • Specifications
  • Downloads
  • Drawings
  • Packing List
  • Others
  • Software

Mightex’s TCN/TCE-1304-U line camera is a cost-effective high-performance B/W line camera, based on a single-line, 3648-pixel CCD chip with USB2.0 (480 Mb/s) interface. CCD line cameras have several advantages over their area-array counterparts, including high optical linear resolution that allows systems developers to use the cameras to capture two-dimensional (2-D) images by moving the object or the CCD perpendicularly to the scan line. TCE-1304-U is a compact line-scan camera ideal for a variety of OEM applications such as industry process control, optical spectroscopy and bio-medical imaging etc.. Setting up the TCE-1304-U line camera is very easy: one simply needs to install the camera’s application software into any PC, and then connect the line camera to the PC using a USB cable. There is no need to install a DAC card or to use an external power supply.

TCN/TCE-1304-UW camera is the window-less version of TCN/TCE-1304-U, with the glass window removed from the image sensor. Therefore, the former is more sensitive to UV and is more suitable for applications that involve coherent light sources.

Features

  • USB2.0 interface
  • No external power supply required
  • Optical integration time adjustable from 0.1ms to 6.5s
  • 3648 pixel silicon linear CCD array
  • 8μm x 200μm pixel size
  • 16-Bit A/D converter
  • Scan rate up to 138 scans/second
  • External trigger capability
  • 4 GPIO pins
  • SDK for user applications
  • Demo software with GUI
  • Compatible to Windows 2000, XP, Vista, 7/8/10

Applications

  • Industrial Process Control
  • Optical Spectroscopy

Performance Specifications

ParameterSpecification
CCDToshiba TCD1304DG
Number of Pixels3648
Pixel Size8μm x 200μm
Spectral Range300nm to 1050nm
200nm to 1050nm (Windowless version)
Pixel Output Clock0.5 MHz
Data Storage on Camera4 Frames
ADC Resolution16 bits
External TriggerYes
Trigger CableACC-CAM-DIN8
Exposure Time Range0.1ms – 6,500ms
GPIOYes (4 programmable I/O’s)
Frame Rate138 scans/second*
Host InterfaceUSB 2.0

* Frame Rate is dependent on exposure time. When exposure time is set to 0.1ms, the camera can achieve 138 scans/second.

SDK Features

Operation SystemsWindows 2000, XP, Vista, Windows 7, 8/8.1, and 10
Minimum RequirementRAM > 64M; Available Hard Disk Space > 10M
USB PortUSB2.0
Multiple CamerasSupported
Device DriverYes
Demo ApplicationYes
Library FilesYes (DLL files and Static Library file)
Example CodesYes (VC++ and Delphi)
Frame Attributes*Exposure Time, Time Stamp, Trigger Event Count, Over Exposure Detection.

* SDK will provide call back, which will send user Frame data and the related attributes of this frame, the attributes include: Exposure time, Time Stamp, Trigger Event Count and Over Exposure Flag.



Document Downloads:

Mechanical Drawing Downloads:

Software Download:

Mechanical Drawing Downloads:

Standard Packing List:

  1. 1x CCD Line Camera (w/o an imaging lens)
  2. 1x USB Cable (Note: Trigger cable ACC-CAM-DIN8 is NOT included and needs to be ordered separately)
  3. 1x CD (containing User’s Guide, SDK Manual, Windows-based application software with GUI, and example codes in VB, C++ and Delphi)

Software Download:

CCD Line Camera F-Mount Lens Adapter (P/N: ACC-LCM-F)

  1. Download ACC-LCM-F installation drawing (.pdf, 51.8kb);
  2. ACC-LCM-F lens adapter photograph

CCD Line Camera Spectral Response

Application Software GUI

Product specifications are subject to change without prior notice. All prices are FOB California, unless otherwise stated. Please call/email for volume pricing.
