USB2.0 3648-Pixel 16-bit CCD Line Camera with External Trigger

$ 17.85

Make a splash this summer with our “Strawberry Sweetheart” swimsuit! Combining timeless British charm with playful modern details, this one-piece is a must-have for beach days, pool parties, and summer holidays. Product Features & Design Signature Style: Featuring a vibrant red and white vertical stripe pattern adorned with a sweet, all-over strawberry print—perfect for that “Instagrammable” summer look. Chic Bow Detailing: Each hip is finished with an oversized, statement red bow that adds a touch of designer flair to your little one’s swimwear collection. Cross-Back Comfort: The elegant cross-back strap design ensures a secure fit that stays in place during active play while providing a high-end boutique aesthetic. Premium Fabric: Crafted from high-quality, quick-dry stretch fabric that is soft against delicate skin and chlorine-resistant for long-lasting wear. Safety & Care Sun-Safe Style: Pair with our matching strawberry bucket hat for extra protection. Easy Care: Machine washable and designed to maintain its vibrant color and shape wash after wash. Why You’ll Love It Whether she’s building sandcastles or learning to swim, this costume offers the perfect balance of luxury kids’ fashion and everyday comfort. It is a top choice for parents looking for boutique girls’ swimwear that stands out from the crowd. Kids Swimwear Size Guide Measurements are provided in centimeters (cm) for precision. Age (Years)HeightChestWaistHips2–3 Years92–98 cm52–54 cm50–51 cm54–56 cm4–5 Years104–110 cm56–58 cm53–54 cm60–62 cm6–7 Years116–122 cm61–63 cm56–57 cm65–67 cm8–9 Years128–134 cm66–69 cm59–61 cm70–73 cm Export to Sheets �� How to Measure To ensure your little one is comfortable, use a soft measuring tape and follow these tips: Chest: Measure around the fullest part of the chest, keeping the tape level. Waist: Measure around the narrowest part of the natural waistline. Hips: Measure around the fullest part of the bottom. Height: Measure from the top of the head to the floor without shoes. Pro Tip: If your child is between sizes or taller than average for their age, we recommend sizing up for extra comfort and longevity.

Customize your product

  • Product Details
  • Specifications
  • Downloads
  • Drawings
  • Packing List
  • Others
  • Software

Mightex’s TCN/TCE-1304-U line camera is a cost-effective high-performance B/W line camera, based on a single-line, 3648-pixel CCD chip with USB2.0 (480 Mb/s) interface. CCD line cameras have several advantages over their area-array counterparts, including high optical linear resolution that allows systems developers to use the cameras to capture two-dimensional (2-D) images by moving the object or the CCD perpendicularly to the scan line. TCE-1304-U is a compact line-scan camera ideal for a variety of OEM applications such as industry process control, optical spectroscopy and bio-medical imaging etc.. Setting up the TCE-1304-U line camera is very easy: one simply needs to install the camera’s application software into any PC, and then connect the line camera to the PC using a USB cable. There is no need to install a DAC card or to use an external power supply.

TCN/TCE-1304-UW camera is the window-less version of TCN/TCE-1304-U, with the glass window removed from the image sensor. Therefore, the former is more sensitive to UV and is more suitable for applications that involve coherent light sources.

Features

  • USB2.0 interface
  • No external power supply required
  • Optical integration time adjustable from 0.1ms to 6.5s
  • 3648 pixel silicon linear CCD array
  • 8μm x 200μm pixel size
  • 16-Bit A/D converter
  • Scan rate up to 138 scans/second
  • External trigger capability
  • 4 GPIO pins
  • SDK for user applications
  • Demo software with GUI
  • Compatible to Windows 2000, XP, Vista, 7/8/10

Applications

  • Industrial Process Control
  • Optical Spectroscopy

Performance Specifications

ParameterSpecification
CCDToshiba TCD1304DG
Number of Pixels3648
Pixel Size8μm x 200μm
Spectral Range300nm to 1050nm
200nm to 1050nm (Windowless version)
Pixel Output Clock0.5 MHz
Data Storage on Camera4 Frames
ADC Resolution16 bits
External TriggerYes
Trigger CableACC-CAM-DIN8
Exposure Time Range0.1ms – 6,500ms
GPIOYes (4 programmable I/O’s)
Frame Rate138 scans/second*
Host InterfaceUSB 2.0

* Frame Rate is dependent on exposure time. When exposure time is set to 0.1ms, the camera can achieve 138 scans/second.

SDK Features

Operation SystemsWindows 2000, XP, Vista, Windows 7, 8/8.1, and 10
Minimum RequirementRAM > 64M; Available Hard Disk Space > 10M
USB PortUSB2.0
Multiple CamerasSupported
Device DriverYes
Demo ApplicationYes
Library FilesYes (DLL files and Static Library file)
Example CodesYes (VC++ and Delphi)
Frame Attributes*Exposure Time, Time Stamp, Trigger Event Count, Over Exposure Detection.

* SDK will provide call back, which will send user Frame data and the related attributes of this frame, the attributes include: Exposure time, Time Stamp, Trigger Event Count and Over Exposure Flag.



Document Downloads:

Mechanical Drawing Downloads:

Software Download:

Mechanical Drawing Downloads:

Standard Packing List:

  1. 1x CCD Line Camera (w/o an imaging lens)
  2. 1x USB Cable (Note: Trigger cable ACC-CAM-DIN8 is NOT included and needs to be ordered separately)
  3. 1x CD (containing User’s Guide, SDK Manual, Windows-based application software with GUI, and example codes in VB, C++ and Delphi)

Software Download:

CCD Line Camera F-Mount Lens Adapter (P/N: ACC-LCM-F)

  1. Download ACC-LCM-F installation drawing (.pdf, 51.8kb);
  2. ACC-LCM-F lens adapter photograph

CCD Line Camera Spectral Response

Application Software GUI

Product specifications are subject to change without prior notice. All prices are FOB California, unless otherwise stated. Please call/email for volume pricing.
