USB2.0 3648-Pixel 16-bit CCD Line Camera with External Trigger

$ 93.28

The Bubble Ruffle Midi Dress is a timeless feminine dress designed to turn heads while remaining effortlessly elegant. This A-line midi dress features a clean strappy bodice that frames the neckline beautifully, flowing into a softly flared skirt finished with a romantic bubble ruffle hem. The result is a refined yet playful statement piece that moves gracefully with every step. Lovingly made in South Africa, this dress is produced in limited runs with attention to fit, finish and fabric quality. Clients may choose between two beautiful fabric options to suit their occasion and personal style: Satin Finish – Soft, fluid and luminous with a luxurious drape that catches the light. Barbie Fabric – Structured, smooth and slightly weightier, offering a polished and sculpted silhouette. Designed to flatter a variety of body shapes, the fitted bodice and gentle A-line skirt create balance and elegance without clinging. The bubble ruffle detail adds a romantic couture-inspired finish, making this dress ideal for bridesmaids, engagement parties, formal events or refined daywear. Pair with minimal heels and delicate jewellery for a modern bridal party look, or dress it up with statement accessories for special occasions. The Bubble Ruffle Midi Dress is equal parts sophistication and charm, a boutique staple for women who appreciate feminine detail and contemporary design. Features A-line midi silhouette Romantic bubble ruffle hem Slim shoulder straps Available in Satin or Barbie Fabric Locally made in South Africa Ideal for bridesmaids & formal occasions Elegant movement and flattering fit IMPORTANT NOTES Important Notes Group Orders: If you’re ordering as part of a bridesmaid group, please let us know at checkout or via message. This ensures we match all garments from the same fabric batch for perfect color consistency. Mommy & Me Option: This item is also available as a coordinated Flower Girl/Mommy and Me set. You can view our kids’ add-on options here. Production Time: Each garment is made to order. Please allow 1–10 working days for production. Lead times may extend by an additional 2–5 working days depending on load-shedding schedules. If you need your order by a specific date, kindly let us know in advance so we can accommodate your timeline. Fabric Options: We offer a variety of fabric types, and a complete guide is available here. If you need help selecting the best fabric for your needs, feel free to reach out to us for personalized assistance. Please note that slight variations in color may occur due to differences in screen settings. Fabric availability may also change from time to time; all listed options are currently in stock. Please allow 1-10 working days for garment production. Lead times may increase by 2-5 days during load-shedding periods, so plan accordingly if you have a specific date. Please let us know if you need your order at a specific date. Slight color variations may occur due to different device screens, and fabric options are subject to availability. plan it

Customize your product

  • Product Details
  • Specifications
  • Downloads
  • Drawings
  • Packing List
  • Others
  • Software

Mightex’s TCN/TCE-1304-U line camera is a cost-effective high-performance B/W line camera, based on a single-line, 3648-pixel CCD chip with USB2.0 (480 Mb/s) interface. CCD line cameras have several advantages over their area-array counterparts, including high optical linear resolution that allows systems developers to use the cameras to capture two-dimensional (2-D) images by moving the object or the CCD perpendicularly to the scan line. TCE-1304-U is a compact line-scan camera ideal for a variety of OEM applications such as industry process control, optical spectroscopy and bio-medical imaging etc.. Setting up the TCE-1304-U line camera is very easy: one simply needs to install the camera’s application software into any PC, and then connect the line camera to the PC using a USB cable. There is no need to install a DAC card or to use an external power supply.

TCN/TCE-1304-UW camera is the window-less version of TCN/TCE-1304-U, with the glass window removed from the image sensor. Therefore, the former is more sensitive to UV and is more suitable for applications that involve coherent light sources.

Features

  • USB2.0 interface
  • No external power supply required
  • Optical integration time adjustable from 0.1ms to 6.5s
  • 3648 pixel silicon linear CCD array
  • 8μm x 200μm pixel size
  • 16-Bit A/D converter
  • Scan rate up to 138 scans/second
  • External trigger capability
  • 4 GPIO pins
  • SDK for user applications
  • Demo software with GUI
  • Compatible to Windows 2000, XP, Vista, 7/8/10

Applications

  • Industrial Process Control
  • Optical Spectroscopy

Performance Specifications

ParameterSpecification
CCDToshiba TCD1304DG
Number of Pixels3648
Pixel Size8μm x 200μm
Spectral Range300nm to 1050nm
200nm to 1050nm (Windowless version)
Pixel Output Clock0.5 MHz
Data Storage on Camera4 Frames
ADC Resolution16 bits
External TriggerYes
Trigger CableACC-CAM-DIN8
Exposure Time Range0.1ms – 6,500ms
GPIOYes (4 programmable I/O’s)
Frame Rate138 scans/second*
Host InterfaceUSB 2.0

* Frame Rate is dependent on exposure time. When exposure time is set to 0.1ms, the camera can achieve 138 scans/second.

SDK Features

Operation SystemsWindows 2000, XP, Vista, Windows 7, 8/8.1, and 10
Minimum RequirementRAM > 64M; Available Hard Disk Space > 10M
USB PortUSB2.0
Multiple CamerasSupported
Device DriverYes
Demo ApplicationYes
Library FilesYes (DLL files and Static Library file)
Example CodesYes (VC++ and Delphi)
Frame Attributes*Exposure Time, Time Stamp, Trigger Event Count, Over Exposure Detection.

* SDK will provide call back, which will send user Frame data and the related attributes of this frame, the attributes include: Exposure time, Time Stamp, Trigger Event Count and Over Exposure Flag.



Document Downloads:

Mechanical Drawing Downloads:

Software Download:

Mechanical Drawing Downloads:

Standard Packing List:

  1. 1x CCD Line Camera (w/o an imaging lens)
  2. 1x USB Cable (Note: Trigger cable ACC-CAM-DIN8 is NOT included and needs to be ordered separately)
  3. 1x CD (containing User’s Guide, SDK Manual, Windows-based application software with GUI, and example codes in VB, C++ and Delphi)

Software Download:

CCD Line Camera F-Mount Lens Adapter (P/N: ACC-LCM-F)

  1. Download ACC-LCM-F installation drawing (.pdf, 51.8kb);
  2. ACC-LCM-F lens adapter photograph

CCD Line Camera Spectral Response

Application Software GUI

Product specifications are subject to change without prior notice. All prices are FOB California, unless otherwise stated. Please call/email for volume pricing.
