USB2.0 3648-Pixel 16-bit CCD Line Camera with External Trigger

$ 89.29

Description Sample Bridesmaid Dresses Try our sample bridesmaid dresses on in the comfort of your own home and follow along with our YouTube tutorials. The perfect way to try before you buy. Luxury Multiway Dresses Long length in the skirt (115cm from the waist to floor, side seams are 112cm) – we can also add an additional 10cm for your taller maids at no cost. extra wide (30cm) and extra long (2m) straps for more coverage a complementary bandeau allowing more ways to wear the dress built in darts for better strap shaping and an illusion sit flat back panel   Ladies Classic and Flutter Sleeve Wrap Dresses: For your maids who like a little more coverage Can be worn two ways, either as a v-neck or turned around for a scoop neck option   Junior Dresses Shoulder to Shoulder is 32cm Waist to floor measurement is 107cm Waist is 68cm The skirt is made from the same fabric as the top wrap   Flower Girl Dresses 18 months to 3 years Shoulder to Shoulder is 23cm Waist to floor measurement is 56cm Waist is 62cm Each skirt is made from a layer of ivory fabric with a tulle overlay 4 to 6 years Shoulder to Shoulder is 23cm Waist to floor measurement is 78cm Waist is 64cm Each skirt is made from a layer of ivory fabric with a tulle overlay 7 to 8 years Shoulder to Shoulder is 23.5cm Waist to floor measurement is 83 Waist is 65.5cm Each skirt is made from a layer of ivory fabric with a tulle overlay   Our dresses are made to order in a variety of sizes: Small Size Luxury Multiway Dress & Jumpsuit, fits UK size 4-8 One Size Luxury Multiway Dress & Jumpsuit, fits UK size 8-14 Plus Size Luxury Multiway Dress & Jumpsuit, fits UK size 16-24 Junior Bridesmaid Wrap Dresses, 8-16 years Flower Girl Wrap Dresses, 18m-3y, 4-6y, 7-8y One Size Ladies Flutter Sleeve Wrap Dress, fits UK size 8-14 Plus Size Ladies Flutter Sleeve Wrap Dress, fits UK size 16-24 One Size Ladies Classic 3/4 Sleeve Wrap Dress, fits UK size 8-14 Plus Size Ladies Classic 3/4 Sleeve Wrap Dress, fits UK size 16-24

Customize your product

  • Product Details
  • Specifications
  • Downloads
  • Drawings
  • Packing List
  • Others
  • Software

Mightex’s TCN/TCE-1304-U line camera is a cost-effective high-performance B/W line camera, based on a single-line, 3648-pixel CCD chip with USB2.0 (480 Mb/s) interface. CCD line cameras have several advantages over their area-array counterparts, including high optical linear resolution that allows systems developers to use the cameras to capture two-dimensional (2-D) images by moving the object or the CCD perpendicularly to the scan line. TCE-1304-U is a compact line-scan camera ideal for a variety of OEM applications such as industry process control, optical spectroscopy and bio-medical imaging etc.. Setting up the TCE-1304-U line camera is very easy: one simply needs to install the camera’s application software into any PC, and then connect the line camera to the PC using a USB cable. There is no need to install a DAC card or to use an external power supply.

TCN/TCE-1304-UW camera is the window-less version of TCN/TCE-1304-U, with the glass window removed from the image sensor. Therefore, the former is more sensitive to UV and is more suitable for applications that involve coherent light sources.

Features

  • USB2.0 interface
  • No external power supply required
  • Optical integration time adjustable from 0.1ms to 6.5s
  • 3648 pixel silicon linear CCD array
  • 8μm x 200μm pixel size
  • 16-Bit A/D converter
  • Scan rate up to 138 scans/second
  • External trigger capability
  • 4 GPIO pins
  • SDK for user applications
  • Demo software with GUI
  • Compatible to Windows 2000, XP, Vista, 7/8/10

Applications

  • Industrial Process Control
  • Optical Spectroscopy

Performance Specifications

ParameterSpecification
CCDToshiba TCD1304DG
Number of Pixels3648
Pixel Size8μm x 200μm
Spectral Range300nm to 1050nm
200nm to 1050nm (Windowless version)
Pixel Output Clock0.5 MHz
Data Storage on Camera4 Frames
ADC Resolution16 bits
External TriggerYes
Trigger CableACC-CAM-DIN8
Exposure Time Range0.1ms – 6,500ms
GPIOYes (4 programmable I/O’s)
Frame Rate138 scans/second*
Host InterfaceUSB 2.0

* Frame Rate is dependent on exposure time. When exposure time is set to 0.1ms, the camera can achieve 138 scans/second.

SDK Features

Operation SystemsWindows 2000, XP, Vista, Windows 7, 8/8.1, and 10
Minimum RequirementRAM > 64M; Available Hard Disk Space > 10M
USB PortUSB2.0
Multiple CamerasSupported
Device DriverYes
Demo ApplicationYes
Library FilesYes (DLL files and Static Library file)
Example CodesYes (VC++ and Delphi)
Frame Attributes*Exposure Time, Time Stamp, Trigger Event Count, Over Exposure Detection.

* SDK will provide call back, which will send user Frame data and the related attributes of this frame, the attributes include: Exposure time, Time Stamp, Trigger Event Count and Over Exposure Flag.



Document Downloads:

Mechanical Drawing Downloads:

Software Download:

Mechanical Drawing Downloads:

Standard Packing List:

  1. 1x CCD Line Camera (w/o an imaging lens)
  2. 1x USB Cable (Note: Trigger cable ACC-CAM-DIN8 is NOT included and needs to be ordered separately)
  3. 1x CD (containing User’s Guide, SDK Manual, Windows-based application software with GUI, and example codes in VB, C++ and Delphi)

Software Download:

CCD Line Camera F-Mount Lens Adapter (P/N: ACC-LCM-F)

  1. Download ACC-LCM-F installation drawing (.pdf, 51.8kb);
  2. ACC-LCM-F lens adapter photograph

CCD Line Camera Spectral Response

Application Software GUI

Product specifications are subject to change without prior notice. All prices are FOB California, unless otherwise stated. Please call/email for volume pricing.
