USB2.0 3648-Pixel 16-bit CCD Line Camera with External Trigger

$ 65.36

Bottom Tier Dolman Sleeve Stretch Maxi Dress – Comfortable, Stylish, and Versatile for Any Occasion The Bottom Tier Dolman Sleeve Stretch Maxi Dress, a perfect blend of comfort, style, and versatility. Whether you’re attending a casual gathering or a semi-formal event, this dress is the ideal choice. The slight overlap wrap top offers a flattering look, while the dolman sleeves provide added style and comfort. The dress gracefully flows into a loose-fitting skirt, gathered at the waist with elastic for a relaxed yet flattering fit. Crafted from high-quality stretch fabric, this maxi dress offers a comfortable flow that moves with you, making it suitable for all-day wear. Whether you’re dressing it up with heels for an evening out or keeping it casual with flats, the Bottom Tier Dolman Sleeve Stretch Maxi Dress is a versatile wardrobe essential. Product Features: Customisable Options: Choose your perfect fit and style. High-Quality Stretch Fabric: Ensures comfort, durability, and a flattering silhouette. Available in Various Colours and Patterns: Find the perfect design to suit your personal style. Relaxed Fit: Offers ease of movement and comfort without sacrificing style. Belted Option: Add a stylish belt for a more defined waist (optional). Dressed Up or Down: Perfect for any occasion, whether casual or semi-formal. Pocket Options: Convenient pockets for added functionality. Inclusive Sizing: Available in all sizes, ensuring a perfect fit for every body type. Made in South Africa: Proudly crafted with attention to detail and local craftsmanship. Special Offer – Mommy and Me Set: This dress is also available as a mommy and me set! Make coordinating outfits easy and stylish for both you and your little one. Perfect For: Casual outings like lunch with friends or a day at the park Semi-formal events like brunch, garden parties, or date nights Mommy and me events, family photoshoots, or coordinated outfits Important Notes: Slight colour variations may occur due to different device screens. Fabric options rotate based on availability. All selections are exclusive and limited edition. Lead Time: Please allow 1-10 working days for garment production. During load-shedding periods, lead times may extend by 2-5 days depending on the severity of the schedule. Contact us for special arrangements if you need your dress by a specific date. Elevate your wardrobe with the Bottom Tier Dolman Sleeve Stretch Maxi Dress – the perfect combination of comfort, style, and versatility for any occasion! We know that every woman is different.  Please have a look at our fabric options to find your ideal fabric option. plan it plan it plan it plan it plan it

Customize your product

  • Product Details
  • Specifications
  • Downloads
  • Drawings
  • Packing List
  • Others
  • Software

Mightex’s TCN/TCE-1304-U line camera is a cost-effective high-performance B/W line camera, based on a single-line, 3648-pixel CCD chip with USB2.0 (480 Mb/s) interface. CCD line cameras have several advantages over their area-array counterparts, including high optical linear resolution that allows systems developers to use the cameras to capture two-dimensional (2-D) images by moving the object or the CCD perpendicularly to the scan line. TCE-1304-U is a compact line-scan camera ideal for a variety of OEM applications such as industry process control, optical spectroscopy and bio-medical imaging etc.. Setting up the TCE-1304-U line camera is very easy: one simply needs to install the camera’s application software into any PC, and then connect the line camera to the PC using a USB cable. There is no need to install a DAC card or to use an external power supply.

TCN/TCE-1304-UW camera is the window-less version of TCN/TCE-1304-U, with the glass window removed from the image sensor. Therefore, the former is more sensitive to UV and is more suitable for applications that involve coherent light sources.

Features

  • USB2.0 interface
  • No external power supply required
  • Optical integration time adjustable from 0.1ms to 6.5s
  • 3648 pixel silicon linear CCD array
  • 8μm x 200μm pixel size
  • 16-Bit A/D converter
  • Scan rate up to 138 scans/second
  • External trigger capability
  • 4 GPIO pins
  • SDK for user applications
  • Demo software with GUI
  • Compatible to Windows 2000, XP, Vista, 7/8/10

Applications

  • Industrial Process Control
  • Optical Spectroscopy

Performance Specifications

ParameterSpecification
CCDToshiba TCD1304DG
Number of Pixels3648
Pixel Size8μm x 200μm
Spectral Range300nm to 1050nm
200nm to 1050nm (Windowless version)
Pixel Output Clock0.5 MHz
Data Storage on Camera4 Frames
ADC Resolution16 bits
External TriggerYes
Trigger CableACC-CAM-DIN8
Exposure Time Range0.1ms – 6,500ms
GPIOYes (4 programmable I/O’s)
Frame Rate138 scans/second*
Host InterfaceUSB 2.0

* Frame Rate is dependent on exposure time. When exposure time is set to 0.1ms, the camera can achieve 138 scans/second.

SDK Features

Operation SystemsWindows 2000, XP, Vista, Windows 7, 8/8.1, and 10
Minimum RequirementRAM > 64M; Available Hard Disk Space > 10M
USB PortUSB2.0
Multiple CamerasSupported
Device DriverYes
Demo ApplicationYes
Library FilesYes (DLL files and Static Library file)
Example CodesYes (VC++ and Delphi)
Frame Attributes*Exposure Time, Time Stamp, Trigger Event Count, Over Exposure Detection.

* SDK will provide call back, which will send user Frame data and the related attributes of this frame, the attributes include: Exposure time, Time Stamp, Trigger Event Count and Over Exposure Flag.



Document Downloads:

Mechanical Drawing Downloads:

Software Download:

Mechanical Drawing Downloads:

Standard Packing List:

  1. 1x CCD Line Camera (w/o an imaging lens)
  2. 1x USB Cable (Note: Trigger cable ACC-CAM-DIN8 is NOT included and needs to be ordered separately)
  3. 1x CD (containing User’s Guide, SDK Manual, Windows-based application software with GUI, and example codes in VB, C++ and Delphi)

Software Download:

CCD Line Camera F-Mount Lens Adapter (P/N: ACC-LCM-F)

  1. Download ACC-LCM-F installation drawing (.pdf, 51.8kb);
  2. ACC-LCM-F lens adapter photograph

CCD Line Camera Spectral Response

Application Software GUI

Product specifications are subject to change without prior notice. All prices are FOB California, unless otherwise stated. Please call/email for volume pricing.
