USB2.0 3648-Pixel 16-bit CCD Line Camera with External Trigger

$ 96.39

The LV Side Table: Elegance in Every Corner The LV Side Table is a masterpiece of contemporary furniture design, meticulously crafted to serve as a versatile accent piece for any modern home. Known by many names—including a corner table, end table, or sofa table—its adaptable nature allows it to transition seamlessly between different roles in your living space. Whether it is supporting a designer lamp in a quiet nook or holding your evening tea by the couch, this table brings a refined aesthetic that elevates the surrounding decor. Constructed with high-grade stainless steel, the base of the LV Side Table offers exceptional durability and a sleek, architectural silhouette. The metal is finished with a premium rose gold plating, providing a warm, luxurious glow that catches the light beautifully. This sophisticated metallic finish ensures the table remains a focal point, offering a trendy yet timeless appeal that complements both minimalist and maximalist interior styles. The crowning glory of this piece is its exquisite marble top. Each slab is carefully selected for its unique veining and natural patterns, ensuring that no two tables are exactly alike. The cool, polished surface of the marble creates a stunning visual contrast against the warm rose gold frame, resulting in a balanced composition of materials that feels both organic and industrial. Designed for convenience as much as style, the LV Side Table is an ideal bedside companion. Its compact footprint makes it perfect for smaller urban apartments, yet its bold design ensures it holds its own in expansive luxury villas. From holding your favorite books to displaying curated art pieces, it functions as a reliable and stylish platform for your daily essentials. Available exclusively through shopps.in, bringing this piece of luxury into your home has never been easier. We pride ourselves on accessibility and quality service, offering reliable delivery all over India. Whether you are decorating a penthouse in Mumbai or a cozy cottage in Shimla, the LV Side Table is shipped with the utmost care, ensuring it arrives at your doorstep ready to transform your living experience.

Customize your product

  • Product Details
  • Specifications
  • Downloads
  • Drawings
  • Packing List
  • Others
  • Software

Mightex’s TCN/TCE-1304-U line camera is a cost-effective high-performance B/W line camera, based on a single-line, 3648-pixel CCD chip with USB2.0 (480 Mb/s) interface. CCD line cameras have several advantages over their area-array counterparts, including high optical linear resolution that allows systems developers to use the cameras to capture two-dimensional (2-D) images by moving the object or the CCD perpendicularly to the scan line. TCE-1304-U is a compact line-scan camera ideal for a variety of OEM applications such as industry process control, optical spectroscopy and bio-medical imaging etc.. Setting up the TCE-1304-U line camera is very easy: one simply needs to install the camera’s application software into any PC, and then connect the line camera to the PC using a USB cable. There is no need to install a DAC card or to use an external power supply.

TCN/TCE-1304-UW camera is the window-less version of TCN/TCE-1304-U, with the glass window removed from the image sensor. Therefore, the former is more sensitive to UV and is more suitable for applications that involve coherent light sources.

Features

  • USB2.0 interface
  • No external power supply required
  • Optical integration time adjustable from 0.1ms to 6.5s
  • 3648 pixel silicon linear CCD array
  • 8μm x 200μm pixel size
  • 16-Bit A/D converter
  • Scan rate up to 138 scans/second
  • External trigger capability
  • 4 GPIO pins
  • SDK for user applications
  • Demo software with GUI
  • Compatible to Windows 2000, XP, Vista, 7/8/10

Applications

  • Industrial Process Control
  • Optical Spectroscopy

Performance Specifications

ParameterSpecification
CCDToshiba TCD1304DG
Number of Pixels3648
Pixel Size8μm x 200μm
Spectral Range300nm to 1050nm
200nm to 1050nm (Windowless version)
Pixel Output Clock0.5 MHz
Data Storage on Camera4 Frames
ADC Resolution16 bits
External TriggerYes
Trigger CableACC-CAM-DIN8
Exposure Time Range0.1ms – 6,500ms
GPIOYes (4 programmable I/O’s)
Frame Rate138 scans/second*
Host InterfaceUSB 2.0

* Frame Rate is dependent on exposure time. When exposure time is set to 0.1ms, the camera can achieve 138 scans/second.

SDK Features

Operation SystemsWindows 2000, XP, Vista, Windows 7, 8/8.1, and 10
Minimum RequirementRAM > 64M; Available Hard Disk Space > 10M
USB PortUSB2.0
Multiple CamerasSupported
Device DriverYes
Demo ApplicationYes
Library FilesYes (DLL files and Static Library file)
Example CodesYes (VC++ and Delphi)
Frame Attributes*Exposure Time, Time Stamp, Trigger Event Count, Over Exposure Detection.

* SDK will provide call back, which will send user Frame data and the related attributes of this frame, the attributes include: Exposure time, Time Stamp, Trigger Event Count and Over Exposure Flag.



Document Downloads:

Mechanical Drawing Downloads:

Software Download:

Mechanical Drawing Downloads:

Standard Packing List:

  1. 1x CCD Line Camera (w/o an imaging lens)
  2. 1x USB Cable (Note: Trigger cable ACC-CAM-DIN8 is NOT included and needs to be ordered separately)
  3. 1x CD (containing User’s Guide, SDK Manual, Windows-based application software with GUI, and example codes in VB, C++ and Delphi)

Software Download:

CCD Line Camera F-Mount Lens Adapter (P/N: ACC-LCM-F)

  1. Download ACC-LCM-F installation drawing (.pdf, 51.8kb);
  2. ACC-LCM-F lens adapter photograph

CCD Line Camera Spectral Response

Application Software GUI

Product specifications are subject to change without prior notice. All prices are FOB California, unless otherwise stated. Please call/email for volume pricing.
