USB2.0 3648-Pixel 16-bit CCD Line Camera with External Trigger

$ 99.23

8 seater round dining Table ✨ Elevate Your Dining Experience with Luxury Design Bring elegance and sophistication into your home with this premium marble top dining table, crafted for modern Indian interiors. Designed with a high-quality stainless steel base in a luxurious gold finish, this table becomes the centerpiece of your dining space. Whether placed in a contemporary apartment in Bangalore or a luxury villa in Kochi, this dining table enhances both style and functionality. �� Premium Materials & Craftsmanship High-grade natural marble top Stainless steel frame with gold electroplating Scratch-resistant and easy to maintain Strong, stable, and long-lasting structure �� Built for durability and everyday use �� Custom Sizes for Every Home 4 Seater Dining Table 6 Seater Dining Table 8 Seater Dining Table �� Custom sizes and finishes available on request �� Designed for Modern Indian Interiors This dining table blends seamlessly with luxury apartments, modern villas, and designer homes. Its clean lines and metallic accents create a perfect balance between minimalism and luxury. �� Why Customers Love This Table Premium look at competitive pricing Unique designer structure Customization options available Ideal for high-end interiors �� Product Specifications Material: Marble Top Stainless Steel Frame Finish Options: Gold / Rose Gold / Chrome / Black Seating Capacity: 4, 6, or 8 Seater Customization: Available (size & finish) Usage: Indoor Delivery: Pan India �� Explore More Designs Looking for more styles? Browse our premium collection here: �� View All Dining Tables ❓ Frequently Asked Questions Q: Is the marble top durable? A: Yes, it is highly durable, scratch-resistant, and easy to maintain. Q: Can I customize the size and color? A: Yes, we offer complete customization options based on your requirements. ⭐ Customer Reviews Elegant and Premium: The dining table completely transformed our dining space. The marble finish and gold frame look stunning. Delivery took slightly longer, but the quality is excellent. Worth the Investment: We were looking for a luxury dining table and this exceeded expectations. The build quality is solid and the finish is flawless. �� Upgrade Your Dining Space Today Invest in a dining table that combines luxury, durability, and modern design. Perfect for homes that value both aesthetics and functionality. Experience the true Shopps.in Ingenuity

Customize your product

  • Product Details
  • Specifications
  • Downloads
  • Drawings
  • Packing List
  • Others
  • Software

Mightex’s TCN/TCE-1304-U line camera is a cost-effective high-performance B/W line camera, based on a single-line, 3648-pixel CCD chip with USB2.0 (480 Mb/s) interface. CCD line cameras have several advantages over their area-array counterparts, including high optical linear resolution that allows systems developers to use the cameras to capture two-dimensional (2-D) images by moving the object or the CCD perpendicularly to the scan line. TCE-1304-U is a compact line-scan camera ideal for a variety of OEM applications such as industry process control, optical spectroscopy and bio-medical imaging etc.. Setting up the TCE-1304-U line camera is very easy: one simply needs to install the camera’s application software into any PC, and then connect the line camera to the PC using a USB cable. There is no need to install a DAC card or to use an external power supply.

TCN/TCE-1304-UW camera is the window-less version of TCN/TCE-1304-U, with the glass window removed from the image sensor. Therefore, the former is more sensitive to UV and is more suitable for applications that involve coherent light sources.

Features

  • USB2.0 interface
  • No external power supply required
  • Optical integration time adjustable from 0.1ms to 6.5s
  • 3648 pixel silicon linear CCD array
  • 8μm x 200μm pixel size
  • 16-Bit A/D converter
  • Scan rate up to 138 scans/second
  • External trigger capability
  • 4 GPIO pins
  • SDK for user applications
  • Demo software with GUI
  • Compatible to Windows 2000, XP, Vista, 7/8/10

Applications

  • Industrial Process Control
  • Optical Spectroscopy

Performance Specifications

ParameterSpecification
CCDToshiba TCD1304DG
Number of Pixels3648
Pixel Size8μm x 200μm
Spectral Range300nm to 1050nm
200nm to 1050nm (Windowless version)
Pixel Output Clock0.5 MHz
Data Storage on Camera4 Frames
ADC Resolution16 bits
External TriggerYes
Trigger CableACC-CAM-DIN8
Exposure Time Range0.1ms – 6,500ms
GPIOYes (4 programmable I/O’s)
Frame Rate138 scans/second*
Host InterfaceUSB 2.0

* Frame Rate is dependent on exposure time. When exposure time is set to 0.1ms, the camera can achieve 138 scans/second.

SDK Features

Operation SystemsWindows 2000, XP, Vista, Windows 7, 8/8.1, and 10
Minimum RequirementRAM > 64M; Available Hard Disk Space > 10M
USB PortUSB2.0
Multiple CamerasSupported
Device DriverYes
Demo ApplicationYes
Library FilesYes (DLL files and Static Library file)
Example CodesYes (VC++ and Delphi)
Frame Attributes*Exposure Time, Time Stamp, Trigger Event Count, Over Exposure Detection.

* SDK will provide call back, which will send user Frame data and the related attributes of this frame, the attributes include: Exposure time, Time Stamp, Trigger Event Count and Over Exposure Flag.



Document Downloads:

Mechanical Drawing Downloads:

Software Download:

Mechanical Drawing Downloads:

Standard Packing List:

  1. 1x CCD Line Camera (w/o an imaging lens)
  2. 1x USB Cable (Note: Trigger cable ACC-CAM-DIN8 is NOT included and needs to be ordered separately)
  3. 1x CD (containing User’s Guide, SDK Manual, Windows-based application software with GUI, and example codes in VB, C++ and Delphi)

Software Download:

CCD Line Camera F-Mount Lens Adapter (P/N: ACC-LCM-F)

  1. Download ACC-LCM-F installation drawing (.pdf, 51.8kb);
  2. ACC-LCM-F lens adapter photograph

CCD Line Camera Spectral Response

Application Software GUI

Product specifications are subject to change without prior notice. All prices are FOB California, unless otherwise stated. Please call/email for volume pricing.
